skeonte3/soc-analyst-homelab

# SOC Analyst Home Lab A fully functional Security Operations Center lab built on Proxmox, simulating a real-world detection and response environment. Used to practice SIEM workflows, attack detection, and threat hunting on Windows endpoints. ## Overview This lab provides hands-on experience with the core technologies and workflows of a SOC analyst: - Endpoint telemetry collection (Sysmon) - SIEM log aggregation and search (Splunk Enterprise) - Adversary simulation (Atomic Red Team) - Network segmentation and isolation - Detection engineering ## Architecture [Internet] → [Spectrum Router] → [Proxmox Host (Dell OptiPlex 7020)] │ ├── vmbr0 (LAN 192.168.1.0/24) │ ├── Pi-hole LXC (CT 100) │ └── Splunk Enterprise VM (101) │ └── vmbr1 (Isolated 10.10.10.0/24) ├── Kali Linux VM (102) └── Windows 10 Victim VM (103) The Windows VM has a second NIC on vmbr0 to forward logs to Splunk while remaining isolated from the home network for attack simulations on vmbr1. ## Tech Stack | Component | Purpose | |-----------|---------| | **Proxmox VE 8.4** | Hypervisor | | **Splunk Enterprise** | SIEM and log analysis | | **Splunk Universal Forwarder** | Log shipping from endpoints | | **Sysmon** (SwiftOnSecurity config) | Windows endpoint telemetry | | **Atomic Red Team** | MITRE ATT&CK-aligned adversary simulation | | **Kali Linux 2026.1** | Attacker platform | | **Windows 10 Pro 22H2** | Target endpoint | | **Ubuntu Server 22.04** | Splunk host OS | ## Lab Specifications - **Host hardware:** Dell OptiPlex 7020, 32GB RAM, 1.8TB SSD - **Network:** Dual bridges (LAN + isolated lab network) - **VM resources:** - Splunk: 4 cores, 8GB RAM, 50GB disk - Kali: 2 cores, 4GB RAM, 40GB disk - Windows 10: 4 cores, 8GB RAM, 80GB disk ## Setup Highlights 1. **Network isolation** — Created an additional Linux bridge (vmbr1) with no gateway to fully isolate attack traffic from the home network and internet. 2. **Dual-NIC Windows VM** — One NIC on the isolated network for receiving attacks, one on the LAN for forwarding telemetry to Splunk. 3. **Sysmon with SwiftOnSecurity config** — Industry-standard config that captures meaningful events without overwhelming the SIEM with noise. 4. **Splunk receiver on port 9997** — Standard forwarder ingestion endpoint configured to receive logs from Windows endpoints. 5. **Atomic Red Team** for repeatable, MITRE-mapped attack simulations. ## Sample Detections Real Splunk searches built and tested in this lab: **Process creation by PowerShell:** index=main EventCode=1 Image="*powershell*" **Encoded PowerShell commands (suspicious):** index=main EventCode=1 Image="*powershell*" CommandLine="*-EncodedCommand*" **All Windows endpoint activity (last hour):** index=main host=win10 ## Techniques Tested | MITRE ATT&CK ID | Technique | Status | |-----------------|-----------|--------| | T1059.001 | PowerShell | ✅ Detected | | (more to come) | | | ## Lessons Learned - **Physical layer matters first.** A bad ethernet cable forced the NIC to negotiate at 10 Mbps with constant link flapping, which presented as application-layer symptoms (ERR_CONTENT_LENGTH_MISMATCH on the Proxmox web UI). Always check `dmesg` for link speed and stability before assuming software issues. - **Config file encoding can silently fail.** Splunk's Universal Forwarder ignored an `inputs.conf` written with Notepad's default encoding. Fixed by rewriting via PowerShell with explicit ASCII encoding. - **Local System doesn't get Sysmon log access by default.** The forwarder service needed to run under an admin account (or have the Sysmon channel SDDL updated) to subscribe to the Sysmon event log. - **Tamper Protection blocks Defender PowerShell commands.** Atomic Red Team requires disabling both Tamper Protection (in the Windows Security UI) and real-time protection. - **SwiftOnSecurity's Sysmon config is the right starting point.** It produces high-signal events without flooding the SIEM with normal Windows noise. ## Repository Contents ## Future Work - Build dashboards visualizing endpoint activity - Install Splunk Security Essentials and ES Content Update - Practice Kali-to-Windows network attacks (nmap, CrackMapExec, Metasploit) - Set up alerting and email notifications - Add Linux endpoint with auditd - Document the full MITRE ATT&CK technique coverage achieved ## Acknowledgments - [SwiftOnSecurity Sysmon Config](https://github.com/SwiftOnSecurity/sysmon-config) - [Atomic Red Team by Red Canary](https://github.com/redcanaryco/atomic-red-team) - [Splunk Free Trial](https://www.splunk.com/) [First Detection] [Powershell output second detection] [Splunk Outputs from detection] [Splunk Creation] [Splunk Processiong Execution Counts] [Splunk Live Events]
