# Anglerfish AI
[](https://github.com/retr0verride/Anglerfish-AI/actions/workflows/ci.yml)
[](pyproject.toml)
[](https://codecov.io/gh/retr0verride/Anglerfish-AI)
Anglerfish AI started as a side experiment while I was standing up a SOC lab with Proxmox, Splunk, and Suricata. It turned into the part that taught me the most. I did the architecture and the security decisions. Claude Code did the implementation. The goal was never to ship a product. It was to understand how the pieces of a honeypot fit together once you have to make the calls yourself: what an attacker is actually looking for and how to show it to them, why a stock honeypot gives itself away the moment it's scanned, which local model to trust and which to keep out, and where the real trust boundaries have to sit. Working those decisions through is what made them stick. Reading about them never did.
It's public because that's what kept the work honest, and because the docs (the design-doc-first trail, the threat model, the audit notes) are worth reading even if you never run it. It's built to run isolated in a VM, never on a network you don't own. docs/THREAT_MODEL.md, docs/PRE_DEPLOY_CHECKLIST.md, and docs/INCIDENT_RESPONSE.md lay out the boundaries and the failure modes. If something here is wrong, careless, or dangerous, tell me. I'd rather hear what I missed than what I caught.
## ⚠️ Legal and ethical use
**Anglerfish AI is a defensive security research tool. By using it you
agree to the following:**
1. **Deploy only on networks you own or have explicit, written
authorisation to operate a honeypot on.** Operating a honeypot on a
third-party network may constitute unauthorised access,
wiretapping, or computer fraud in your jurisdiction.
2. **You are responsible for compliance** with your local laws and the
acceptable-use policies of your hosting provider, network operator,
and registrar.
3. **Captured credentials, payloads, and shell sessions are sensitive
data.** Treat them as such. They may include real credentials
inadvertently submitted by misconfigured automation. The credential
database is encrypted at rest with AES-GCM; do not export it in
plaintext.
4. **No warranty.** Anglerfish AI is provided "AS IS"; see
[LICENSE](LICENSE).
The first-boot wizard requires explicit acknowledgement of these terms
before any service is enabled.
## Architecture
┌──────────────────────────────────────────────────────┐
│ ANGLERFISH AI VM │
│ │
bait NIC ──────┤ Lure (native asyncssh on :2222 by default) │
(hostile) │ │ │
│ │ unknown commands (HTTP, loopback :8421) │
│ v │
│ Bridge HTTP server │
│ │ │
│ v │
│ AIBridgeService ── sanitize → rate-limit → prompt │
│ │ → Ollama → cap → fallback │
│ v │
│ ┌─────────────┐ │
│ │ Ollama LLM │ <──── loopback or trusted IP ───── service NIC
│ └─────────────┘ (qwen3:14b default) │
│ │ │
│ v │
│ Threat engine ── MITRE ATT&CK tagger ── webhook │
│ │ │
│ v │
│ Session store (SQLite at /var/lib/anglerfish) │
│ │ │
│ v │
│ Dashboard (FastAPI + WebSockets) ─── operator UI ── service NIC
│ │ │
│ v │
│ Credentials DB (SQLite + AES-GCM, dedup via HMAC) │
│ Fingerprinter (SSH banner, JA3, HASSH, Tor exits) │
│ Geo lookup (MaxMind GeoLite2) │
└──────────────────────────────────────────────────────┘
The honeypot VM has two network interfaces:
* **Bait**: exposed to hostile traffic. Runs the lure SSH listener
(native asyncssh) on the configured port. Egress is dropped at
nftables level except for DNS.
* **Service**: private, firewalled. Reaches Ollama (loopback or a
single trusted IP) and the operator dashboard. Nothing else.
A compromised Anglerfish must not be able to pivot to other systems.
nftables rules generated at first boot enforce that egress on the
service interface is restricted to the configured Ollama and dashboard
endpoints only. See [`nftables/anglerfish.nft`](nftables/anglerfish.nft).
## Components
| Component | Status | Purpose |
| --------------- | ------------- | ------------------------------------------------------------------ |
| `config/` | **shipped** | Pydantic configuration models + settings loader |
| `bridge/` | **shipped** | Sanitise / rate-limit / Ollama client / fallback / orchestrator / HTTP server |
| `threat/` | **shipped** | MITRE ATT&CK technique tagging + scorer + webhook alerter |
| `fingerprint/` | **shipped** | SSH banner parser + JA3/HASSH hash helpers + Tor exit list |
| `geo/` | **shipped** | MaxMind GeoLite2 wrapper (async via `to_thread`) |
| `credentials/` | **shipped** | SQLite + AES-GCM encrypted credential intelligence DB |
| `sessions/` | **shipped** | SQLite-backed persistent session store |
| `dashboard/` | **shipped** | FastAPI + WebSocket UI with deep-sea bioluminescent theme |
| `wizard/` | **shipped** | First-boot Typer wizard, generates secrets, writes `.env` |
| `cli/` | **shipped** | `anglerfish` and `anglerfish-wizard` entry points + ASCII banner |
| `models/` | **shipped** | Shared session / response / threat / fingerprint / geo / credential types |
| `lure/` | **shipped** | Native asyncssh SSH honeypot |
| `iso/` | **shipped** | live-build recipe, hooks, build script |
| `systemd/` | **shipped** | Hardened unit files for every long-running service |
Every shipped Python module is gated on `ruff`, `mypy --strict`, and
`pytest --cov-fail-under=90`.
## Documentation
| Document | What it covers |
| ------------------------------------------------ | ---------------------------------------------------------------------- |
| [`docs/PRODUCT.md`](docs/PRODUCT.md) | Thesis, design principles, the seven capabilities, non-goals |
| [`docs/ROADMAP.md`](docs/ROADMAP.md) | Eleven-stage build plan from foundation to full adaptive-deception |
| [`docs/design/TEMPLATE.md`](docs/design/TEMPLATE.md) | Template each stage's design doc fills in before code is written |
| [`docs/ARCHITECTURE.md`](docs/ARCHITECTURE.md) | Module-by-module walkthrough, IPC boundaries, where to look when |
| [`docs/API_REFERENCE.md`](docs/API_REFERENCE.md) | Bridge + dashboard REST endpoints, WebSocket protocol, integration examples |
| [`docs/INSTALL.md`](docs/INSTALL.md) | Prerequisites, ISO + Proxmox/QEMU deployment, wizard walkthrough |
| [`docs/MODEL_SETUP.md`](docs/MODEL_SETUP.md) | Local LLM install: hardware sizing, Ollama tuning, three-tier model stack, integrity hashes |
| [`docs/proxmox.md`](docs/proxmox.md) | Proxmox-specific bridge prep, VM config, GPU passthrough, snapshots |
| [`docs/proxmox-lab.md`](docs/proxmox-lab.md) | Strict-lab variant: air-gapped bait bridge, PCAP capture, snapshot/reset workflow |
| [`docs/PRE_DEPLOY_CHECKLIST.md`](docs/PRE_DEPLOY_CHECKLIST.md) | Top-to-bottom verification before exposing to attacker traffic |
| [`docs/INCIDENT_RESPONSE.md`](docs/INCIDENT_RESPONSE.md) | Playbook for pivot, breach, audit-log gap, upstream CVE |
| [`docs/RUNBOOK.md`](docs/RUNBOOK.md) | Day-2 ops: credentials rotation, geo updates, 7 recovery scenarios |
| [`docs/THREAT_MODEL.md`](docs/THREAT_MODEL.md) | STRIDE table, trust boundaries, crypto inventory, known limitations |
| [`SECURITY.md`](SECURITY.md) | Vulnerability disclosure policy, supported versions, scope |
| [`CONTRIBUTING.md`](CONTRIBUTING.md) | Quality gates, branch/commit style, PR checklist |
| [`docs/ONBOARDING.md`](docs/ONBOARDING.md) | 30-minute tour for a new contributor |
| [`docs/AUDIT.md`](docs/AUDIT.md) | Substage audit checklist applied before every slice commit |
## Quick start (development)
### Prerequisites
* Python 3.11+
* `pip` and `venv`
* For live LLM testing: a reachable Ollama instance (loopback or a
trusted-remote IP)
### Install
git clone https://github.com/retr0verride/Anglerfish-AI.git
cd Anglerfish-AI
python3.11 -m venv .venv
source .venv/bin/activate # PowerShell: .\.venv\Scripts\Activate.ps1
pip install -e ".[dev]"
pre-commit install --install-hooks
### Run the quality gates
The pipeline is the source of truth. Every commit must pass these:
ruff check .
ruff format --check .
mypy
pytest # enforces --cov-fail-under=90
`pre-commit run --all-files` runs all of the above in one go.
### Inspect configuration
export ANGLERFISH_DASHBOARD__SESSION_SECRET="$(openssl rand -base64 32)"
export ANGLERFISH_CREDENTIALS__ENCRYPTION_KEY="$(openssl rand -base64 32)"
anglerfish banner
anglerfish config show
anglerfish --version
### Run the bridge against a local Ollama
anglerfish bridge serve --host 127.0.0.1 --port 8421
### Run the dashboard against an empty state
uvicorn --factory anglerfish.dashboard.app:create_app \
--host 127.0.0.1 --port 8420
### Run the first-boot wizard manually
anglerfish-wizard run --env /tmp/anglerfish.env
## Configuration reference
Configuration is read from environment variables prefixed `ANGLERFISH_`,
with `__` as the nested-section delimiter. A `.env` file in the working
directory is also honoured. See [`.env.example`](.env.example) for the
full list.
Two values are **required** with no default and must be supplied by
the operator (the first-boot wizard generates them):
| Variable | Format |
| ----------------------------------------- | ---------------------------- |
| `ANGLERFISH_DASHBOARD__SESSION_SECRET` | ≥32-character string |
| `ANGLERFISH_CREDENTIALS__ENCRYPTION_KEY` | base64-encoded 32-byte key |
### Ollama endpoint policy
The Ollama endpoint host is validated at config time:
* **Always accepted:** any loopback IP (`127.0.0.0/8`, `::1`) and the
literal hostname `localhost`.
* **Conditionally accepted:** an IP literal (and **only** an IP
literal) that matches the value of
`ANGLERFISH_OLLAMA__TRUSTED_REMOTE_HOST`.
* **Always rejected:** every other hostname (including DNS names that
happen to resolve to a trusted IP), every non-matching IP, and the
unspecified address `0.0.0.0`.
This is a structural property. There is no override flag.
## Threat model and security boundaries
* **The honeypot is a target.** Attacker input is length-capped and
stripped of C0 control characters before reaching a prompt template;
every model response is silently capped to a configured maximum.
* **The LLM is untrusted.** Prompt injection from attacker commands is
mitigated structurally: the attacker's text always lives in its own
user message, and the system prompt instructs the model to treat any
user message as a shell command, not as instructions.
* **Rate limiting is mandatory.** The bridge enforces a global
concurrency cap plus a per-session token bucket. When either fires,
the attacker still receives a plausible response (drawn from the
scripted fallback set) so the limiter cannot be used as a probe.
* **Credentials are encrypted at rest.** AES-GCM under a key supplied
via `ANGLERFISH_CREDENTIALS__ENCRYPTION_KEY`. Deduplication uses
HMAC-SHA256 fingerprints under a separate key derived from the
master, so unique-counts and equality lookups never touch the
plaintext.
* **Service network is one-way egress.** nftables rules allow
connections only to the configured Ollama and dashboard endpoints.
Bait-interface egress is dropped entirely (except DNS).
* **systemd hardening.** Every long-running unit uses
`ProtectSystem=strict`, `NoNewPrivileges`, an explicit
`SystemCallFilter`, a minimised `CapabilityBoundingSet`, and
`PrivateTmp`.
## MITRE ATT&CK coverage
The default rule set tags the following techniques. Add more by
constructing a custom `TechniqueRule` tuple and passing it to
`score_session`.
| Technique | Description |
| ---------- | ------------------------------------------ |
| T1003 | OS Credential Dumping |
| T1016 | System Network Configuration Discovery |
| T1018 | Remote System Discovery |
| T1033 | System Owner/User Discovery |
| T1046 | Network Service Scanning |
| T1049 | System Network Connections Discovery |
| T1053 | Scheduled Task/Job (persistence) |
| T1057 | Process Discovery |
| T1059.004 | Unix Shell |
| T1070 | Indicator Removal on Host |
| T1071 | Application Layer Protocol |
| T1082 | System Information Discovery |
| T1083 | File and Directory Discovery |
| T1098 | Account Manipulation (persistence) |
| T1105 | Ingress Tool Transfer |
| T1136 | Create Account (persistence) |
| T1496 | Resource Hijacking (cryptominers) |
| T1543 | Create or Modify System Process (persistence) |
Sessions that touch persistence techniques get a +20 score bonus and
flip the `persistence_attempted` flag, which is what the alerter
watches.
## ISO build
sudo apt install live-build debootstrap squashfs-tools xorriso \
isolinux syslinux-common
sudo cp -r . /tmp/anglerfish-ai
sudo ./iso/build.sh
Produces `iso/build/anglerfish-ai-
.iso` plus a `.sha256`
checksum. See [`iso/README.md`](iso/README.md) for full details.
The ISO boots directly into a text console and runs the first-boot
wizard on tty1 before any networked service comes up.
## Repository layout
Anglerfish-AI/
├── src/anglerfish/
│ ├── bridge/ # Ollama AI middleware + rate limiting + HTTP server
│ ├── dashboard/ # FastAPI + WebSocket UI + templates + static
│ ├── threat/ # Threat scoring + MITRE ATT&CK tagging + alerter
│ ├── fingerprint/ # SSH/JA3/HASSH + Tor exit list
│ ├── geo/ # MaxMind GeoLite2 wrapper
│ ├── credentials/ # AES-GCM encrypted credential intelligence DB
│ ├── sessions/ # SQLite-backed persistent session store
│ ├── config/ # Pydantic config models
│ ├── models/ # Shared runtime data models
│ ├── wizard/ # First-boot configuration wizard
│ ├── lure/ # Native asyncssh SSH lure
│ └── cli/ # Entry points + ASCII banner
├── tests/ # pytest test suite (≥90% coverage gate)
├── nftables/ # nftables ruleset template
├── iso/ # live-build recipe + hooks + build script
├── systemd/ # Hardened systemd unit files
├── assets/ # SVG icon, ASCII art
├── docs/ # Architecture diagrams, docs
├── pyproject.toml
├── .pre-commit-config.yaml
└── README.md
## Disclosure on implementation
Anglerfish AI is architected by a human and implemented with the
assistance of Claude Code (Anthropic). Every file is reviewed before
it lands. The quality pipeline (`ruff`, `mypy --strict`,
`pytest --cov-fail-under=90`) is what decides whether code ships, not
the assistant's confidence. Pull requests are held to the same gate.
## License
