ssteelfactor-oss/Kestrel

# Kestrel ## The problem with existing tooling SharpHound, BloodHound's collector, runs as a .NET assembly. It generates LDAP traffic in patterns that no legitimate domain workstation produces, and it does so from a managed runtime that EDR hooks and inspects. EDR flags it not because it exploits anything, but because the behavioral signature is unmistakable. Same story with ADRecon, PowerView, and most Python-based alternatives: the runtime is the fingerprint. This is a real problem for defenders running internal audits. You need to enumerate your own domain to find misconfigurations before an attacker does, but the common tooling announces itself loudly — both in its runtime and in the *shape* of the traffic it puts on the wire. ## A different approach ## How it works IDirectorySearch *pSearch = NULL; ADsGetObject(ldapPath, &IID_IDirectorySearch, (void **)&pSearch); pSearch->lpVtbl->SetSearchPreference(pSearch, prefs, 2); pSearch->lpVtbl->ExecuteSearch(pSearch, filter, attrs, count, &hSearch); The one exception is **ADWS endpoint detection**, which performs a bare TCP connect to port 9389 on each DC (connect + `SO_ERROR` check, no payload, no WCF framing). It is the only behavior in Kestrel that is not a plain LDAP query — a single, payload-free probe directed at the DC, never at a member host. It is called out explicitly rather than folded into the "looks like normal LDAP" claim. Groups are resolved by **Well-Known RID + Domain SID**, not by name. Kestrel works correctly on domains installed in any language (English, Russian, German, etc.) without hardcoded group-name strings. ## Scope and non-goals Kestrel's philosophy is a hard boundary, not a preference. A capability belongs in Kestrel only if **both** hold: (1) its traffic targets only the DC / directory (or a SYSVOL read that is part of normal Group Policy processing), and (2) it succeeds with the rights of an ordinary authenticated domain user. By design, Kestrel therefore **does not**: - send packets to member hosts (no host-touch enumeration of any kind); - collect logged-on sessions, query SAMR/remote registry, or scan SMB shares; - require local-administrator rights on any target; - write to the directory — every operation is read-only; - attempt to evade or disguise itself. It produces a *low and familiar* footprint, which is not the same as *no* footprint. Anything that needs to touch a member host or needs privileges above a normal domain user is out of scope by definition and belongs to a separate, explicitly labeled active tool — not to Kestrel. ## Requirements - Windows, domain-joined machine - Authenticated domain user account (no elevated privileges required for most scans) - Visual Studio 2019+ with Windows SDK - Linked libraries: `activeds.lib`, `adsiid.lib`, `ws2_32.lib`, `advapi32.lib` ## Build Open `Kestrel.sln` in Visual Studio, select **Release | x64**, build. For a self-contained binary with no runtime DLL dependencies: Project Properties → C/C++ → Code Generation → Runtime Library → **Multi-threaded (/MT)** ## Modules ### v0.1 — Five passive scans (`adws_scan.c`) All queries are read-only. Zero packets sent to member hosts (the ADWS probe targets DCs only, as noted above). | Module | What it does | | --------------------------- | --------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------- | | **ADWS Endpoint Detection** | Probes port 9389/TCP per DC. Raw TCP connect, SO\_ERROR verification, no WCF framing. The one non-LDAP behavior; payload-free; DC-directed only. | | **Computer Topology** | Full computer inventory with SPN-based service inference. MSSQLSvc → SQL Server, WSMAN → WinRM, TERMSRV → RDP. One LDAP query covers the entire domain. | | **Delegation Risks** | Separates three categories: unconstrained delegation (TGT forwarding), constrained delegation (msDS-AllowedToDelegateTo), and Protocol Transition / S4U2Self (UAC 0x1000000). Reported separately — different risk profiles. | | **LAPS Coverage** | Detects legacy LAPS (ms-Mcs-AdmPwdExpirationTime) and Windows LAPS 2023+ (msLAPS-EncryptedPasswordHistory). Splits computer population into managed/unmanaged with percentage breakdown. | | **Stale Computers** | Uses lastLogonTimestamp as primary reference — it replicates across DCs, unlike lastLogon which is per-DC only. Both values reported side by side. | ### v0.2 — ACL edge extraction (`KestrelACL.C`) Extended Rights GUID→name mapping is built dynamically from `CN=Extended-Rights,CN=Configuration` — no hardcoded GUID tables. Classified edge types: `GenericAll`, `WriteDACL`, `WriteOwner`, `GenericWrite`, `ExtendedRight`, `WriteProperty`, `CreateChild`, `DeleteChild`, `Self`. Two read modes: - **Plan A** — per-object `IDirectoryObject` bind (requires elevated rights in some environments) - **Plan B** — reads `nTSecurityDescriptor` directly from the LDAP search column (works for any authenticated domain user) Plan A is attempted first. On the first access denial, Kestrel switches to Plan B automatically for all remaining objects, keeping the run within ordinary-user rights. ### v0.3 — Transitive group membership (`KestrelGroup.c`) Expands high-value groups using `LDAP_MATCHING_RULE_IN_CHAIN` (OID `1.2.840.113556.1.4.1941`). One LDAP query per group — the DC performs full recursive traversal server-side, with no client-side BFS. Groups are located by **RID**, not by name: | RID | Group | | ------- | ------------------------------------- | | 512 | Domain Admins | | 518 | Schema Admins | | 519 | Enterprise Admins | | 520 | Group Policy Creator Owners | | 521 | Read-only Domain Controllers | | 526 | Key Admins | | 527 | Enterprise Key Admins | | 548–551 | Account/Server/Print/Backup Operators | After expansion, group membership is cross-referenced against the ACL edges from v0.2 to surface attack paths: `member → [via group] → EdgeType → target`. ## Roadmap | Version | Status | Description | | ------- | ------ | -------------------------------------------------------------------------------------------------------- | | v0.1 | ✅ | Five passive AD scans | | v0.2 | ✅ | ACL edge extraction via IDirectoryObject / nTSecurityDescriptor | | v0.3 | ✅ | Transitive group membership via LDAP\_MATCHING\_RULE\_IN\_CHAIN | | v0.4 | ✅ | In-memory graph from ACL + membership + delegation data. Structured export (JSON / YAML). | | v0.5 | 🔲 | BFS shortest-path finder: any principal → Domain Admins. Pure in-memory traversal over v0.4 data — no additional queries, no host contact. | Every roadmap item stays inside the boundary in [Scope and non-goals](#scope-and-non-goals). Edge types that would require touching member hosts — logged-on sessions, local-admin relationships via remote SAM — are deliberately excluded from Kestrel's graph. ## Code quality **SAL 2.0 annotations** on every function signature, validated by PREfast (`/analyze`) at compile time. `_Must_inspect_result_` on HRESULT-returning functions, `_Outptr_` vs `_Out_` where semantics differ. **Single rootDSE resolution** — `defaultNamingContext` and `configurationNamingContext` are read once at startup and passed as parameters. No redundant DC round-trips. **No runtime dependencies** when built with `/MT` — a single executable, no VCRUNTIME DLLs required on the machine it runs from. ## Related ## Author [@ssteelfactor-oss](https://github.com/ssteelfactor-oss) Security research and COM/Windows internals
