# EL — A tribute to Edmond Locard

_{AI-generated image.}

A multi-agent DFIR orchestrator for the SANS SIFT Workstation, built for the [SANS Find Evil 2026](https://findevil.devpost.com/) competition and designed as a reusable forensic investigation framework. 📺 **Watch the 4:46 demo walkthrough:** [EL demo (YouTube)](https://youtu.be/QuliIYfjqrI) — a live-terminal screencast with narration that installs EL, runs a real forensic investigation end-to-end, hits an on-screen **self-correction ("Bug found & fixed") at [2:07](https://youtu.be/QuliIYfjqrI?t=127)**, then shows the case + executive reports. Full [chapter index & content guide](docs/demo_video.md); the same self-correction loops (insufficient-finding → code fix → test-lock) are documented in [`sample-reports/SRL-2018-shakedown.md`](sample-reports/SRL-2018-shakedown.md) and [§ Self-correction](#self-correction). **Judges:** start at [`docs/JUDGES.md`](docs/JUDGES.md) — single-page quickstart with a 5-min contract verification, a 30-min end-to-end run against the public M57-Jean scenario, and a reference table mapping the six judging criteria to specific files and commands. ## What it does Hand EL a piece of evidence — memory image, pcap, EVTX file, CloudTrail JSON, Azure sign-in / M365 UAL export, extracted-artifacts directory, Velociraptor / UAC / dfTimewolf collection bundle, Falco event JSONL, E01 disk image (NTFS / ext4 / APFS), live Linux system root, or extracted filesystem tree (Windows / Linux / macOS / Android / iOS) — and it produces: - **A structured Findings ledger** — every claim ships with the tool, version, command, output sha256, supporting/refuting hypotheses, and an adversarial-review verdict. No claim without evidence. - **A ranked hypothesis table** — Heuer's *Analysis of Competing Hypotheses* over 33 case-level hypotheses (ransomware, APT espionage, insider exfil, BEC, supply chain, brute force, cloud persistence, C2 beaconing, opportunistic commodity, process injection, credential access, lateral movement, persistence variants, mobile-spyware persistence, container escape, K8s privilege escalation, plus a null benign-no-incident). - **A Markdown report** with executive summary, hypothesis ranking, most diagnostic findings, MITRE ATT&CK techniques implicated, IOC catalog, and a per-finding disconfirming-evidence checklist. - **A self-contained HTML case view** (`el report --html`) — single-file dark-theme dashboard with ACH ranking, filterable findings grid, detail drawer, SVG attack-chain graph pulled from the Kùzu substrate, ATT&CK coverage heatmap grouped by tactic, and Diamond Model projection. Zero CDN, works from `file://`; `--watch` mode re-renders live as agents emit findings. - **A built-in HTTP viewer** (`el serve`) — local loopback web server on `http://127.0.0.1:8089/` that browses every case under `/opt/EL/cases/`. Snap-confined browsers (default Chromium on Ubuntu) cannot read `/opt/` via `file://`; this is the supported workaround. Optional systemd `--user` service install (`el serve --install-service` or `./install.sh --with-serve`) for auto-start at login. - **A STIX 2.1 bundle** + **machine-readable findings.json** + **per-case Kùzu graph** + **forensic_audit.log** + **per-case CLAUDE.md** for follow-on interactive analysis. The contract is hard: EL refuses to advance to synthesis while any finding remains `red_review.status == "unresolved"`, and `confidence="insufficient"` is a first-class output. **An honest "I don't know" beats a confident guess.** ## Architecture flowchart TB %% ============ ARCHITECTURAL TRUST BOUNDARIES (dashed boxes) ============ %% Crossing a dashed border = crossing a trust boundary. %% These are ARCHITECTURAL guardrails enforced in code (intake strips %% write-bits; ACH is pure Python; the LLM never scores/writes/blocks), %% NOT prompt-text guardrails. subgraph LEGEND["◆ LEGEND — architecture pattern & guardrail types  (dashed box = trust boundary)"] direction TB L_PAT["PATTERN: Multi-Agent Framework
Python coordinator over 34 specialist agents
+ Claude Code session integration (Playwright MCP + skills)"] L_EVID["Evidence zone — ARCHITECTURAL guardrail
strict read-only; write-bits stripped at intake"] L_DET["Deterministic zone — ARCHITECTURAL guardrails
court-vetted CLI tools · pure-Python ACH · schema rejects evidence-less findings"] L_LLM["Advisory LLM zone — the ONLY PROMPT-BASED guardrails
(Red Reviewer / executive-brief prompt text); never scores, writes, or blocks"] L_PAT ~~~ L_EVID ~~~ L_DET ~~~ L_LLM end subgraph ZONE_EVID["🔒 TRUST BOUNDARY · Evidence zone
STRICT READ-ONLY — chain of custody
(write-bits stripped at intake; originals never modified)"] direction TB subgraph INPUTS["Evidence inputs (16 validated shapes, 27 routed kinds)"] direction LR IN_MEM["memory image
(.raw / .vmem / .mdd)"] IN_DISK["disk image
E01 / raw / NTFS / ext4 / APFS
+ VHDX / VMDK"] IN_PCAP["pcap / pcapng
(also pcap-collection)"] IN_LOG["EVTX / .evt /
CloudTrail / Entra / M365 /
k8s-audit / Falco events"] IN_FS["FS tree
Windows / Linux / macOS /
Android / iOS / QNAP"] IN_VELO["Velociraptor bundle
+ UAC collection
+ dfTimewolf bundle"] IN_LIVE["live Linux system
UAC + Tracee eBPF"] end INTAKE["Intake
hash + manifest
read-only enforcement"] INPUTS --> INTAKE end subgraph ZONE_DET["TRUST BOUNDARY · Deterministic pipeline
court-vetted CLI tools · Pydantic-validated findings
NO LLM in the scoring path"] direction TB TRIAGE["Triage
magic bytes + directory shape
sets evidence_kind"] COORD{"Coordinator
state machine
intake → triage → hypothesis_gen →
parallel_investigate → correlate →
adversarial_review → synthesize → report → done"} TRIAGE --> COORD subgraph AGENTS["34 specialist agents (one per evidence kind, chained as applicable)"] direction TB A_MEM["MemoryForensicator
18 vol3 plugins + Baseliner
+ MemProcFS FindEvil corroboration"] A_USR["UserActivityAgent
Office MRU FILETIMEs + TypedPaths
+ drive-letter↔USB map
+ removable-staging detector"] A_RDP["RDPBruteForceAnalyst
inbound :3389 from external IPs
brute-force cluster + breach"] A_DISK["DiskForensicator
Sleuth Kit + EWF + NTFS/ext4/APFS mount"] A_WIN["WindowsArtifactAgent
11 EZ Tools + BAM/DAM + IE5 + XP .evt"] A_LIN["LinuxForensicator
utmp/wtmp/btmp + systemd-journal +
cron + SSH + Father rootkit + UAC mode"] A_MAC["MacOSForensicator
+ Mandiant macos-UnifiedLogs (Rust)"] A_AND["AndroidForensicator
+ MVT (Pegasus / Predator IOCs)"] A_IOS["IOSForensicator
+ MVT mercenary-spyware check"] A_NET["NetworkAnalyst
scapy + Zeek + Suricata + tshark
+ JA3/JA4+ + RITA-algorithm beaconing"] A_LOG["LogAnalyst
EvtxECmd + Hayabusa + Sigma correlation"] A_CRED["CredentialAnalyst"] A_LAT["LateralMovementAnalyst"] A_PS["PowerShellAnalyst
EID 4104 + 4103 + PSReadline"] A_CLOUD["CloudForensicator
CloudTrail / VPC / Entra / M365 / GCP"] A_MAIL["EmailForensicator
PST + OST + inbound phishing"] A_BROWSE["BrowserForensicator
+ Hindsight (Chromium family)"] A_EXEC["ExecutionCorroborator"] A_ENDP["EndpointAnalyst
Velociraptor v0.7+ schema
(PEDump / ProcessInfo / MFT / Linux)"] A_TIME["TimelineSynthesist
Plaso → Timesketch push"] A_HUNT["ThreatHunter
YARA / YARA-X auto-prefer + stego-carrier"] A_MAL["MalwareTriage
capa + FLOSS + pefile + 21 families"] A_LOGC["LogCorpus
multi-host SOC logs → per-format parsers
(Win Event XML / eCAR / Zeek JSON / ASA / Snort / syslog)"] A_LIVE["LiveResponseCollector
UAC IR-triage + Tracee eBPF"] A_DFTW["DFTimewolfDispatcher
recipe + sub-artifact inventory"] A_K8S["K8sAuditAnalyst"] A_CONT["ContainerForensicator
Falco events → escape / k8s privesc"] end COORD --> AGENTS subgraph SHARED["Shared per-case substrate"] direction LR LEDGER[("findings.sqlite
(Pydantic-validated)")] GRAPH[("graph.kuzu
Locard entities + edges")] KNOW[("~/.el/knowledge.sqlite
(cross-case IOC + imphash)")] end AGENTS --> LEDGER AGENTS --> GRAPH AGENTS -. ioc registration .-> KNOW CORR["Correlator
cross-agent Kùzu graph queries"] ACH["ACH Engine
33 hypotheses × all findings
Heuer diagnostic scoring
(pure Python — no LLM)"] RED["Red Reviewer
rule-based challenger (always, deterministic)
+ LLM augmentation (advisory only)
blocks SYNTHESIZE until every unresolved Finding resolves"] LEDGER --> CORR --> ACH --> RED RED -- "any unresolved?" --> COORD REPORT["Reporter
deterministic projection of Findings"] RED --> REPORT subgraph OUT["Judge-facing outputs (sealed at DONE)"] direction LR O_MD["report.md
narrative.md"] O_HTML["case.html
(dark theme, zero CDN)"] O_STIX["stix-bundle.json
(deterministic UUID5 ids,
Layer-3 recurrence labels)"] O_JSON["findings.json"] O_SIGMA["reports/sigma_rules/
SPL · KQL · Lucene packs"] O_EXEC["execution_log.jsonl
execution_log.md
traceability_matrix.md"] O_SEAL["seal.json
+ tar.gz archive"] end REPORT --> OUT SERVE["el serve
loopback HTTP viewer :8089"] O_HTML --> SERVE end INTAKE --> TRIAGE subgraph ZONE_LLM["TRUST BOUNDARY · Advisory LLM zone
Claude Code session skills (no API key needed)
NEVER scores ACH · NEVER writes evidence · NEVER blocks"] direction TB MCP["Playwright MCP server
(.mcp.json → npx @playwright/mcp)
browser automation over the web view"] SKILL_RR["skill: el-red-review
fulfils deferred adversarial challenger"] SKILL_AI["skill: el-ai-brief
fulfils deferred executive brief"] end subgraph PUSH["External push targets (opt-in, env-var configured)
outside all trust boundaries"] direction LR P_TS["Timesketch
(.plaso upload)"] P_OCTI["OpenCTI
(STIX bundle)"] P_MISP["MISP
(STIX bundle)"] P_CAPE["CAPE Sandbox
(dynamic analysis)"] end REPORT -. opt-in .-> PUSH SERVE <-. drive / screenshot .-> MCP RED -. "deferred when inside Claude Code
(CLAUDECODE=1, no API key)" .-> SKILL_RR REPORT -. "deferred when inside Claude Code" .-> SKILL_AI SKILL_RR -. verdicts merge .-> LEDGER SKILL_AI -. brief re-renders .-> REPORT classDef sub fill:#0d1117,stroke:#30363d,color:#c9d1d9 classDef zoneEvid fill:#1c1408,stroke:#d29922,stroke-width:3px,stroke-dasharray:6 4,color:#e3b341 classDef zoneDet fill:#0a1410,stroke:#3fb950,stroke-width:3px,stroke-dasharray:6 4,color:#7ee787 classDef zoneLLM fill:#160e1f,stroke:#bc8cff,stroke-width:3px,stroke-dasharray:6 4,color:#d2a8ff classDef zoneExt fill:#161313,stroke:#8b949e,stroke-width:2px,stroke-dasharray:4 4,color:#8b949e classDef legendPat fill:#0d1117,stroke:#58a6ff,stroke-width:2px,color:#79c0ff class INPUTS,AGENTS,SHARED,OUT,LEGEND sub class ZONE_EVID zoneEvid class ZONE_DET zoneDet class ZONE_LLM zoneLLM class PUSH zoneExt class L_PAT legendPat class L_EVID zoneEvid class L_DET zoneDet class L_LLM zoneLLM ### Agents | Agent | Owns | |---|---| | `Triage` | First-touch: hash, file-magic, evidence-kind classification, vol3 banner OS detection, directory-shape recognition (Windows-artifacts / Velociraptor / Android / iOS / macOS — mobile shapes detected by cheap `is_dir()` probes before the expensive filesystem walk) | | `MemoryForensicator` | Volatility 3 plugins (`pslist`, `psscan`, `pstree`, `cmdline`, `malfind --dump`, `netstat`, `netscan`, `dlllist`, `svcscan`, `modules`, `modscan`, `ldrmodules`, `handles`, `getsids`, `ssdt`, `driverirp`, `filescan`, `mftscan`); psscan-pslist hidden-process diff; modules-vs-modscan unlinked-driver diff; ldrmodules three-list reflective-injection diff; PE-header / process-anomaly detection; credential-access carve-out (lsass / winlogon / csrss); optional Memory Baseliner image-vs-image diff; **MemProcFS FindEvil corroboration** (mounts the image as a virtual FS, runs Ulf Frisk's built-in injection scanner — independent second tool satisfies Red Reviewer's single-tool challenger automatically; FUSE harvest is watchdog-bounded so a stalled mount degrades gracefully instead of hanging); **cloud/CDN-aware netscan beacon scoring** (benign Microsoft/Azure/Akamai/Google/AWS/Cloudflare/Fastly/Dropbox CIDRs + weak web-port residue downgraded below `H_C2_BEACONING`, RITA-style interval analysis flagged for escalation); raw `ntoskrnl` banner fallback for truncated/over-4GB acquisitions (routes to carve-only + emits a precise `insufficient` finding rather than a false negative) | | `UserActivityAgent` | Chains after MemoryForensicator on Windows. Reconstructs the per-user project-access timeline from in-memory NTUSER hives — Office MRU FILETIME decoder (`[F…][T][O…]*path` REG_SZ values), TypedPaths (Explorer address-bar history), MountedDevices ASCII-column → drive-letter↔USB-serial map. **Removable-staging detector** flags Office-MRU paths that resolve to a USB drive letter AND contain corporate-project fragments — emits findings tagged `H_INSIDER_DATA_STAGING` + `H_INSIDER_DATA_EXFIL` (proves intentional collection, not accidental sync) | | `RDPBruteForceAnalyst` | Chains after UserActivityAgent on Windows. Walks the netscan JSONL the memory forensicator already produced; clusters inbound TCP/3389 connections per external (non-RFC1918) source IP with CLOSED / SYN_RCVD / ESTABLISHED breakdown. ≥10 connections per source = brute-force cluster (`H_BRUTE_FORCE`); ESTABLISHED > 0 = breach (separate Finding so attempted vs. authenticated edges are visible at a glance). Disjoint from `LateralMovementAnalyst` which scores RFC1918↔RFC1918 RDP | | `DiskForensicator` | Sleuth Kit (`mmls`, `fls`, `mactime`); EWF integrity verification + `ewfmount` + per-partition (and no-partition fallback) walk; NTFS mount + artifact extraction; ext4 mount; APFS mount via `fsapfsmount`; disk anomaly scoring (PsExec service binary, PyInstaller `_MEI` temp dirs, svchost/lsass outside System32, exe-in-Temp, non-MS scheduled tasks, mimikatz-named binaries, vssadmin shadow-copy deletion traces); **encrypted-artifact surfacing** (BitLocker recovery-key `.txt`, aescrypt `.aes`, PGP/GnuPG key material `pubring.kbx`/`secring.gpg`/`private-keys-v1.d`/`.asc`/`.gpg`/`.pgp`, VeraCrypt/TrueCrypt `.tc`/`.hc` containers → advisory `H_DISK_ENCRYPTED`; surfacing only — decryption is out-of-scope by design) | | `WindowsArtifactAgent` | Extracted-artifacts directory pipeline — auto-chained after DiskForensicator extracts: MFTECmd, RECmd-Kroll-batch, AmcacheParser, AppCompatCacheParser, PECmd, EvtxECmd, SrumECmd, SBECmd, JLECmd, LECmd, RBCmd, BAM/DAM registry subtree decoding, ActivitiesCache.db (Windows Timeline) parsing | | `LinuxForensicator` | Extracted Linux filesystem tree (ext4 mount or pre-extracted) — pulls `/etc`, `/var/log`, `/var/spool/cron`, per-user histories + SSH. 5 detectors: shell-history malicious (reverse shell / download cradle / base64 pipe / persistence / defense evasion / priv esc / credential access), `/etc/ld.so.preload`, auth-log failure burst, `authorized_keys` anomaly, cron suspicious. **Father-rootkit detection** (multi-directory LD_PRELOAD + magic GID + backdoor-port pattern matcher). Also accepts **UAC collection** evidence shape with the same detectors | | `MacOSForensicator` | Extracted macOS filesystem (APFS mount or pre-extracted). Pulls `/private/etc`, `/Library/Launch{Agents,Daemons,StartupItems}`, per-user Safari/KnowledgeC/Quarantine/LoginItems/LaunchAgents, `/private/var/log`. 4 detectors: LaunchAgent/Daemon suspicious-path persistence, shell-history malicious (shared Linux pattern library), Safari `QuarantineEventsV2` raw-IP / suspicious-TLD download source, Safari `Downloads.plist` anomalies. **Mandiant macos-UnifiedLogs** (Rust tracev3 parser, ~100x faster than `log show`, runs on Linux): walks `.logarchive` bundles + `/private/var/db/diagnostics/Persist/` for high-signal events (TCC consent / AMFI rejection / Gatekeeper / Sandbox violations / kextd) | | `AndroidForensicator` | Pre-extracted Android filesystem tree (Belkasoft / UFED / adb-pull). Pulls `/data/system/*.xml+db`, `/data/adb/`, `/data/local/tmp/`, ANR traces, tombstones, per-app messenger DBs. 4 detectors: rooted device (Magisk markers), sideloaded APKs (packages.xml installer heuristic with OEM exemptions), `/data/local/tmp` executable staging, messenger presence. **MVT** (Amnesty Tech Mobile Verification Toolkit): runs `check-androidqf` / `check-backup` against the artifact set with the published Pegasus / Predator / Triangulation STIX2 IOC bundles → activates the otherwise-dormant `H_MOBILE_SPYWARE_PERSISTENCE` scorer | | `IOSForensicator` | Pre-extracted iOS filesystem tree (checkm8 / GrayKey / Cellebrite). Pulls SystemVersion.plist, `/private/var/mobile/Library/` user-data DBs (SMS, AddressBook, CallHistory, knowledgeC, interactionC, Safari, Mail, Notes, Health), per-app iTunesMetadata + BundleMetadata + Info.plist, provisioning profiles. 4 detectors: jailbreak indicators, sideloaded apps (no iTunesMetadata + non-Apple bundle id), provisioning-profile presence, messenger / privacy-tool presence (Signal / Telegram / Wickr / Session / Threema / Onion Browser / KeepSafe / Burner / ProtonMail / Tutanota / …). **MVT** `check-fs --fast` + `check-backup -n` runs after iLEAPP for mercenary-spyware IOC matching against Amnesty Tech bundles | | `NetworkAnalyst` | pcap parsing via scapy: flows, DNS, HTTP Hosts + URIs + User-Agents, TLS SNI, suspicious-port flagging, Zeek replay with DGA entropy + DNS tunneling + SMB admin-share write detection, wire-layer Kerberos triage, JA3 reputation. **JA4+ family** (FoxIO ja4.py — TLS / HTTP / SSH / QUIC client fingerprinting; supplements not replaces JA3). **Statistical beaconing detection** (RITA-algorithm Hill & Bestard formula on Zeek conn.log: ≥0.85 score on `ts_score`+`disp_score`/2 = high-confidence `H_C2_BEACONING` lift) | | `LogAnalyst` | EvtxECmd → high-value Event ID extraction (4624, 4625, 4672, 4688, 4697, 4698, 4720, 4732, 4769, 4776, 1102, 7045); SIGMA rule evaluator. **Hayabusa Sigma correlation** (v3+ composite-rule output → second high-confidence finding when correlation rules fire — e.g. brute-force = "N failed + 1 success in 1 min") | | `CloudForensicator` | AWS CloudTrail JSON + AWS VPC Flow Logs + Azure Entra sign-in logs + M365 Unified Audit Log + Azure Activity + GCP Cloud Audit. Sniffs input shape and dispatches; detectors for brute / spray, legacy-auth bypass, impossible travel, OAuth consent, inbox-rule external forwarding | | `EndpointAnalyst` | Velociraptor collection bundles. v0.6 era: Pslist / Netstat / Autoruns / Prefetch / TaskScheduler. **v0.7+ schema**: Generic.System.PEDump, Windows.Memory.ProcessInfo, Windows.NTFS.MFT, Windows.Forensics.{Amcache, Lnk, Jumplists, Shellbags, UserAssist}, Linux.Sys.Pslist / Linux.Network.Netstat / Linux.Forensics.BashHistory | | `BrowserForensicator` | Chrome / Edge / Firefox history, cookies, login-data, downloads from extracted user profiles. **Hindsight** (Ryan Benson) for Chromium-family deep parsing: Local Storage, IndexedDB, Session Storage, autofill, login data, sync evidence, extensions, FedCM. Emits exfil-shape findings on forum-upload paths / anon-share hosts / consumer-webmail | | `CredentialAnalyst` | Kerberos anomalies from EVTX — RC4-HMAC TGS-REQ (Kerberoasting), AS-REQ failure burst, krbtgt-service TGS-REQ (golden-ticket smell) | | `PowerShellAnalyst` | EID 4104 ScriptBlock decoding (base64 + gzip) + malicious pattern match, EID 4103 module logging, PSReadline history, transcription logs | | `SigmaAnalyst` | Native SIGMA rule evaluator over parsed EVTX — EventID-indexed pre-filter, 90%-coverage modifier set, tag-to-hypothesis mapping | | `EmailForensicator` | `.pst` / `.ost` / `.msg` / `.eml` parsing via `libpff` + `libolecf` wrappers | | `ExecutionCorroborator` | Cross-artifact execution confirmation — Prefetch × Amcache × Registry × EvidenceOfExecution overlap | | `LateralMovementAnalyst` | Cross-host pivot detection from EVTX 4624/4625/4648/4672/4769 + Security-Auditing event chaining | | `TimelineSynthesist` | Plaso `log2timeline.py --parsers win_gen --hashers md5,sha256 --timezone UTC` + `psort.py` + `pinfo.py` (opt-in via `--timeline`). **Timesketch push** (opt-in via `EL_TIMESKETCH_URL` + token) — auto-uploads the `.plaso` storage to a configured Timesketch sketch at `case_id` for collaborative review | | `Correlator` | Kùzu graph queries — top destination IPs, cross-host shared processes, entity counts, netscan-triage cluster lifting | | `ThreatHunter` | Auto-generates a per-case YARA file from extracted IOCs; sweeps the input + analysis dir; uses `el hunt ` CLI for standalone re-sweeps | | `MalwareTriage` | Per-region `.dmp` strings extraction + 19-family fingerprint library (mimikatz / cobalt strike / metasploit / empire / darkcomet / njrat / remcos / agent tesla / hancitor / trickbot / qakbot / icedid / sliver / ip_lookup_chain / angler / nuclear / fiesta EKs / asprox / dyre). Also scans non-memory analysis text (pcap summaries, EVTX CSVs, fls bodyfiles) for the same fingerprints; `capa` + `FLOSS` integration with ATT&CK technique attribution on dumped PEs / shellcode | | `RedReviewer` | Rule-Based Challenger always runs (Office-spawn-shell, JIT carve-out for credential targets, LOLBin, network-context, low-confidence corroboration, single-evidence); LLM challenger augments when `ANTHROPIC_API_KEY` is set | | `LiveResponseCollector` | Triage-routed for `live-linux-system` evidence kind (input is `/` or a chroot with active `/proc`). Runs UAC IR-triage profile + Tracee eBPF time-bounded capture (`EL_TRACEE_DURATION` env, 5–600s default 60). Stages results so downstream `LinuxForensicator` UAC mode picks them up | | `DFTimewolfDispatcher` | Triage-routed for `dftimewolf-bundle` (recipe JSON/YAML + `dftimewolf.log` alongside artifacts). Records *provenance* (which dfTimewolf recipe + modules ran — chain-of-custody value) and emits a per-kind sub-artifact inventory with operator follow-up commands; sub-artifacts (Plaso storage, CloudTrail JSON, .pcap, .evtx) re-route through existing EL agents on operator re-run | | `ContainerForensicator` | Triage-routed for `falco-events` (Falco JSONL with `rule` + `priority`). Aggregates by rule + priority; classifies hits into container-escape / K8s-privesc buckets via curated rule-name keyword families; emits `H_CONTAINER_ESCAPE` / `H_K8S_PRIVILEGE_ESCALATION` findings + per-event medium-confidence detail for top CRITICAL/ERROR events | | `K8sAuditAnalyst` | Kubernetes audit-log JSON parser (audit.k8s.io/v1) — surfaces RBAC abuse, ServiceAccount token operations, privileged-pod admission, exec/portforward into privileged pods | Plus the **ACH engine** (Heuer-style scoring; not a Claude agent — pure Python) which emits a ranked-hypothesis Finding and writes a per-case `ach_matrix.json`. ### Skills Tool wrappers, shared by agents, hardened against the operator-tier gotchas documented in [Protocol SIFT](https://github.com/teamdfir/protocol-sift)'s five `SKILL.md` files (memory-analysis, sleuthkit, plaso-timeline, windows-artifacts, yara-hunting). | Skill | Wraps | |---|---| | `vol3` | Volatility 3 plugins; `--offline` opt-in to skip symbol-download hangs; `--dump` integration; 18 plugins wired | | `sleuthkit` | `mmls`, `fls`, `mactime` (`-z UTC` default), `ewfinfo`, `ewfverify`, `ewfmount -X allow_other`, `img_stat`, `fsstat`, `tsk_recover`, `mount_ntfs` / `mount_linux_ro` / `mount_apfs_ro`, `extract_windows_artifacts` | | `ezt` | EZ Tools via `dotnet`: EvtxECmd (`--maps` default), MFTECmd (`--at` default), RECmd (`--bn Kroll_Batch.reb` default), AmcacheParser, AppCompatCacheParser, PECmd, SBECmd, JLECmd, LECmd, SrumECmd, RBCmd | | `plaso` | `log2timeline.py` with SKILL defaults (`--parsers win10 --hashers md5,sha256 --timezone UTC`), `psort.py`, `pinfo.py` | | `scapy_pcap` | pcap parsing in pure Python — flows, DNS, HTTP Host/URI/User-Agent, TLS SNI | | `cloudtrail` / `azure_signin` / `m365_audit` / `gcp_audit` / `aws_vpc_flow` | JSON / JSONL parsers; shape-sniff dispatch from `cloud_forensicator` | | `velociraptor` | Velociraptor JSONL collection parser; Pslist / Netstat / Autoruns / Prefetch / TaskScheduler | | `kerberos_triage` | Zeek `kerberos.log` detectors — RC4-HMAC Kerberoasting, AS-REQ brute/spray, krbtgt golden-ticket smell | | `sigma_engine` | Native SIGMA rule evaluator — modifier set + condition grammar covering ~90% of community Windows rules | | `ioc_extract` | Regex extractor (IPv4, IPv6, domain, URL, MD5/SHA1/SHA256, email, registry key, Windows path); defang-aware; noise-filtered (timestamps, version strings, X.509 OID labels, secp256k1/secp256r1 curve constants, file-extension TLDs, Windows internals); ubiquitous-IOC suppression from `~/.el/knowledge.sqlite` | | `yara_hunt` | `yara` wrapper + per-case rule generator from extracted IOCs | | `dump_analysis` | Pure-Python ASCII + UTF-16LE strings extraction from memory dumps; structural fingerprints (MZ header, PE signature, NOP sleds) | | `memory_baseliner` | Memory Baseliner `-proc/-drv/-svc` comparisons; supports both image-vs-image (`-b `) and JSON baseline workflows; auto-patched for vol3 ≥ 2.5 API | | `capa` / `floss` | `capa` rule-pack resolver + shellcode-mode dispatch + FLOSS decoded-string extraction — ATT&CK technique attribution on PE / shellcode dumps | | `bam_dam` / `win_timeline` | BAM/DAM registry subtree decoding via `regipy` + ActivitiesCache.db (Windows Timeline) via `sqlite3 ro=immutable` | | `user_activity_memory` | Office MRU FILETIME decoder (`[F…][T][O…]*path` REG_SZ in `Software\Microsoft\Office\\\User MRU\\File MRU`) + MountedDevices REG_BINARY hex-ASCII column reassembly + USBSTOR vendor/product/serial regex. Joins drive letters to physical USB devices, decodes per-file last-open timestamps tied to Microsoft account identities (ADAL/LiveId), surfaces corporate-project paths on removable media as a staging signal | | `rdp_brute_force` | Walks vol3 netscan JSONL for inbound TCP/3389 from external IPs, clusters per source-IP with CLOSED / SYN_RCVD / ESTABLISHED breakdown. Threshold of 10 connections/source separates brute-force from port-scan noise; ESTABLISHED > 0 = breach. RFC1918 source filter so internal lateral-movement RDP is left to `lateral_movement_analyst` | | `linux_artifacts` / `linux_triage` | Extract + detect on Linux filesystem trees — 5 detectors keyed on the Linux pattern library (reverse shell / download cradle / base64 pipe / persistence / defense evasion / priv esc / credential access) | | `macos_artifacts` / `macos_triage` | Extract + detect on macOS filesystem trees — 4 detectors on LaunchAgents, Quarantine events, Safari downloads, shell history (delegates to Linux library) | | `android_artifacts` / `android_triage` | Extract + detect on Android filesystem trees — 4 detectors (rooted device, sideloaded APK, `/data/local/tmp` staging, messenger presence) | | `ios_artifacts` / `ios_triage` | Extract + detect on iOS filesystem trees — 4 detectors (jailbreak indicators, sideloaded app, provisioning profile, messenger / privacy-tool presence) | | `disk_anomaly` | 9 SKILL/MITRE-grounded path patterns matched against fls bodyfiles | | `rule_challenger` | Deterministic adversarial-review rules baseline; JIT carve-out for credential-access targets (lsass / winlogon / csrss) | | `seal` | Per-case sha256 manifest + `merkle_root` + `tar.gz` archive emission at coordinator-DONE | | `knowledge` | `~/.el/knowledge.sqlite` cross-case IOC + family-attribution store; rarity bucketing (rare / uncommon / common / ubiquitous) | | `stix_import` | STIX 2.1 inbound bundle ingestion into `~/.el/knowledge.sqlite` with provenance tag | | `memprocfs` | Ulf Frisk's MemProcFS (Tier 1.1) — mounts a Windows memory image as a virtual FUSE filesystem; runs the built-in FindEvil scanner; harvests `findevil.csv` + YARA matches for Red Reviewer corroboration of vol3 plugin hits | | `mvt` | Amnesty Tech Mobile Verification Toolkit (Tier 1.2) — `mvt-ios check-fs` / `check-backup`, `mvt-android check-androidqf` / `check-backup`. STIX2-IOC matching against published Pegasus / Predator / Reign / Triangulation indicator bundles | | `hindsight` | Ryan Benson `pyhindsight` (Tier 1.3) — Chromium-family deep forensics via subprocess CLI; JSONL output. Profile-discovery walks for History+Cookies pairs; 14 tests verify shape detection + lazy-iter parsing | | `timesketch` | `timesketch-api-client` + `timesketch-import-client` (Tier 1.5). Opt-in `.plaso` upload to a configured Timesketch sketch at coordinator DONE; absent env vars = clean no-op | | `uac` | Unix Artifact Collector (Tier UAC-prep) — live response collection on Linux/Unix targets via `uac -p ir_triage` profile; output structure consumed by LinuxForensicator UAC mode | | `father_rootkit_detection` | Specialised LD_PRELOAD / magic-GID / source-port detector for the Father Linux rootkit family (Tier UAC-prep) — multi-evidence-shape search across chkrootkit / live_response / [root] tree | | `ja4` | FoxIO JA4+ family fingerprinting (Tier 2.6) — TLS / HTTP / SSH / QUIC client signatures via `ja4.py` (BSD-3-Clause + FoxIO License 1.1). Supplements (does not replace) `ja3_reputation` | | `network_beaconing` | Statistical C2-beacon detector (Tier 2.3) — pure-Python implementation of the published RITA / AC-Hunter formula (Hill & Bestard); runs over Zeek conn.log; ≥0.85 score with ≥10 connections per tuple = `H_C2_BEACONING` lift | | `cape_client` | CAPEv2 REST client (Tier 2.4) — opt-in via `EL_CAPE_URL` + token. Submits binaries, polls `tasks/status/`, parses report JSON (signatures + score + family). Cuckoo-successor dynamic analysis | | `m365_collect` | Invictus IR Microsoft-Extractor-Suite wrapper (Tier 2.1) — PowerShell subprocess. Connect-M365 + Get-{UAL, MailItemsAccessed, MessageTraceLog, AdminAuditLog, EntraIDSignInLogs, OAuthPermissionsGraph, MailboxRules, InboxRule}. App-secret or username/password auth | | `azurehound_triage` | Pure-Python AzureHound JSON triage (Tier 2.2) — privileged Entra ID role assignments, external-guest admins, high-risk OAuth scopes (Mail.ReadWrite / Files.ReadWrite.All / Directory.ReadWrite.All). No Neo4j dependency | | `tracee` | Aqua Security Tracee eBPF wrapper (Tier 2.7) — bounded-duration syscall + file + network event capture from a live Linux kernel. Default 60s window, 5-600s via `EL_TRACEE_DURATION`. Requires root + BTF kernel | | `ti_push` | OpenCTI + MISP submission (Tier 3.1) — at coordinator DONE, posts `reports/stix-bundle.json` to a configured OpenCTI (pycti `import_bundle_from_json`) and/or MISP (PyMISP `upload_stix`). Opt-in via env vars; absent = no-op | | `dftimewolf_bundle` | dfTimewolf output-directory parser (Tier 3.2) — recipe + log + sub-artifact inventory. `looks_like_dftimewolf_bundle()` shape detector for triage routing | | `falco_events` | Falco event-JSONL parser (Tier 3.4) — rule-keyword classification into container-escape / K8s-privesc buckets; preserves CRITICAL / ERROR ordering for high-priority findings | | `macos_unifiedlogs` | Mandiant macos-UnifiedLogs Rust port wrapper (Tier 4.3) — tracev3 / `.logarchive` parsing on Linux. ~100x faster than `log show`. Runs on extracted macOS filesystem trees alongside the existing macos_triage detectors | | `sigma_export` | pySigma multi-backend rule-conversion (Tier 4.1) — at coordinator DONE writes `reports/sigma_rules/sigma_rules.{splunk.spl, elasticsearch.lucene, opensearch.lucene, kusto.kql}` so analysts can deploy the same SIGMA content EL evaluates in-process. ~2,400 rules per backend on the bundled Hayabusa pack | ### State machine The coordinator drives every investigation through a fixed nine-state finite state machine. Illegal transitions raise; the gate at `ADVERSARIAL_REVIEW → SYNTHESIZE` refuses to score hypotheses while any Finding's `red_review.status` is `unresolved`. See **[`docs/state-machine.md`](docs/state-machine.md)** for the Mermaid diagram, per-state guarantees, and the authoritative transition table. ### Self-correction EL is not a free-running LLM that "reasons its way" through a case. Self-correction is **architectural**: every agent emit path can fail into a downgrade-and-continue branch rather than a crash, and the result is visible in the ledger as a first-class `insufficient` finding the analyst can read. Within-run primitives that exercise this on real cases: - **Partition-table parse fallback.** When `mmls` returns rc=1 on an E01 whose partitioning isn't standard (recovery partitions, hybrid GPT/MBR), `disk_forensicator` falls back to whole-image `fls` on the raw EWF stream rather than aborting. *Surfaced on SRL-2018's `dc-disk` first.* - **vol3 symbol-cache miss.** When a Windows memory image needs an ISF symbol pack that isn't local, `memory_forensicator` emits an `insufficient` finding with the exact `downloads.volatilityfoundation.org/volatility3/symbols/...` URL to fetch, and downstream agents see the gap explicitly instead of treating the empty plugin output as "no evidence found." - **Hibernation-layer parse failure.** Vol3 can't always decode the compressed hibernation layer on pre-Win10 builds; the hibernation shell-history hook (FOR508 ex 2.5) catches rc=1 per-plugin and records the failure shape so an analyst reading the ledger knows *why* the hibernation channel is silent, not just *that* it is. - **Per-snapshot VSS mount retry.** When `vshadowmount` of one snapshot fails (FUSE / sudo / NTFS-parser hiccup), the cross- snapshot diff records the failure on that snapshot and continues to the next — one bad shadow doesn't blow up the diff for the other 24. *Surfaced on SRL-2018-r2's 25-snapshot DC disk.* - **Streaming primitive replaces the OOM-killer-prone API.** `scapy.rdpcap()` loads the entire pcap into a Python list and OOMs on multi-GB merged captures; the `scapy_pcap` skill uses `PcapReader` (packet-by-packet) with a configurable cap whose truncation is recorded in the JSON summary so the analyst sees the bound explicitly. *Surfaced on M57-pcaps: 4.7 GiB merge SIGKILLed the python process with no traceback — fix landed at the skill level so every future pcap consumer inherits the streaming path.* - **Ubiquitous-IOC suppression.** The cross-case knowledge store buckets every IOC by recurrence; observations seen in 30+ prior cases are classified `ubiquitous` and *do not* lift any hypothesis. Prevents `13.107.6.254` (Microsoft Telemetry) from flipping ACH rankings just because it appears in netscan output. - **Pair-detection advisory at intake.** When two device inputs share byte size + name-root (e.g. SRL-2018's `file-mem` ↔ `file-mem-snap5`, SRL-2015's `nromanoff-mem` ↔ `nromanoff-baseline-mem`), the bundle CLI emits a paired-capture finding and the analyst can opt into Memory-Baseliner cross-diff with `--baseline`. The detection is advisory rather than auto-rewire so a bad pair-name guess can't silently drop a device. The pattern: every guard ships as a downgrade-and-continue, every downgrade leaves a record, and every record is something the analyst (or the next case-run) can read and act on. **Self-correction across runs is a corollary of within-run self-honesty**: because the agents are honest about what they couldn't extract, the next iteration knows what to fix. The [accuracy report](docs/accuracy_report.md#self-correction-sequences-during-real-case-work) walks four end-to-end sequences where this loop closed on real third-party evidence. ## Install ### Prerequisite — Protocol SIFT EL is the runtime implementation of **[Protocol SIFT](https://github.com/teamdfir/protocol-sift)** — the AI-agent operating contract layered on top of the SANS SIFT Workstation. Protocol SIFT ships: - `~/.claude/CLAUDE.md` — operator charter (forensic constraints, installed tool paths, evidence-read-only rules) - `~/.claude/skills//SKILL.md` — per-domain operator-tier playbooks for Plaso, Sleuth Kit, memory analysis, Windows artifacts, YARA hunting EL inherits both verbatim. The charter's "tool output IS evidence" rule, the read-only-on-`/cases/` constraint, the UTC-everywhere convention, and the no-hallucinations posture all originate in Protocol SIFT — EL builds the multi-agent orchestrator that runs to that contract. **Install Protocol SIFT first** (follow the upstream README) or EL will not have the charter or skill files it expects from `~/.claude/`. The included [`docs/protocol-sift.md`](docs/protocol-sift.md) documents the inheritance contract in detail. ### Host requirements | Resource | Minimum | Recommended | Driver | |---|---|---|---| | RAM | 8 GB | **16 GB** | DC-class `evtx_parsed.csv` is 6+ GB / 5 M+ rows; `iter_events` materialises it into a Python list. Runs with <8 GB RAM will OOM on domain-controller / long-running-server images. 16 GB also lets disk + memory investigations run in parallel and leaves headroom for vol3 on 8 GB memory captures | | vCPU | 2 | **4** | EvtxECmd, AmcacheParser, RECmd and bulk_extractor are multi-threaded; vol3 runs plugins sequentially but the agent launches several per case | | Disk | 100 GB | **300–500 GB** | Each DC / RD case produces 6–10 GB of exports before sealing; sealed archives compound. 100 GB forces cleanup cycles during a corpus run | | Base OS | — | SANS SIFT Workstation (Ubuntu 22.04) | Sleuth Kit, Plaso, EZ Tools runtime, dotnet, bulk_extractor already present | ### Install steps git clone https://github.com/threatroute66/EL.git /opt/EL cd /opt/EL ./install.sh `install.sh` is idempotent. It: 1. Snapshots host state (`dpkg -l`, `/opt`, vol3 presence) into `provisioning/snapshots/` for chain of custody. 2. Installs apt packages from `provisioning/apt-packages.txt` (currently `yara` + `gh`). 3. Downloads and installs UAC (Unix Artifact Collector) v3.3.0 to `/opt/uac/` for live response collection. 4. Downloads missing EZ Tools that EL requires but may be absent from SIFT's default installation. 5. Creates a Python venv (prefers `virtualenv`, falls back to `python -m venv`). 6. `pip install -e .[dev]` (volatility3, scapy, stix2, kuzu, anthropic, pydantic, etc.). 7. Snapshots post-install state and writes a diff. 8. Runs `el doctor`. Re-verify anytime with `./install.sh --doctor` or `make doctor`. Optional tools we detect but don't install: Memory Baseliner, zeek, suricata, tshark, PECmd. See `provisioning/optional-tools.txt`. ## Usage # Survey the host: which tools are present, schema sane, Kùzu importable el doctor # Investigate evidence end-to-end el investigate /cases/memory.img --case-id wkstn-01 el investigate /cases/capture.pcap el investigate /cases/cloudtrail.json --case-id apt-29-cloud el investigate /cases/extracted-artifacts/ --case-id host-42-disk el investigate /cases/velociraptor-bundle/ --case-id endpoint-collection # Optional flags el investigate --baseline /path/to/baseline.json # Memory Baseliner comparison el investigate --timeline # also run Plaso super-timeline (slow) # Multi-host case: run N devices as ONE bundle. Each device runs the full # per-host pipeline into cases//devices//; a synthesis pass # then merges every finding, recomputes ACH on the union (cross-host evidence # sums into the same hypothesis), and auto-renders the cross-host dashboard # at cases/_combined//combined.html (joint ACH heatmap, unified # swim-lane timeline, merged Locard graph, per-host drill-down). el investigate-bundle apt-intrusion \ -d dc:/cases/dc.E01 -d ws01:/cases/ws01.E01 -d ws02:/cases/ws02-mem.raw # Bundles (and any input ≥ EL_AUTODETACH_GB, default 4 GB) auto-detach to a # systemd --user unit so a multi-hour run survives logout; --foreground forces # attached. The web index links every bundle's combined dashboard + per-host # reports inline. # Re-render report from an existing case ledger (no re-investigation) el report /opt/EL/cases/wkstn-01 # Also render a self-contained HTML case view (reports/case.html) el report /opt/EL/cases/wkstn-01 --html # Live-update mode: re-render on every findings.sqlite change. Open # case.html?watch=3 in a browser for auto-reload every 3 s. el report /opt/EL/cases/wkstn-01 --html --watch # Browse all case reports via a local HTTP server — needed when the # default browser is a snap (Chromium on Ubuntu) that can't read # /opt/ from file://. Loopback-only by default. el serve # http://127.0.0.1:8089/ el serve --port 9000 # custom port el serve --root /opt/EL/cases/srl-admin-memory # single case # Install the viewer as a systemd --user service: auto-starts at # next login and survives reboots (once user-linger is enabled). # Ships the unit at ~/.config/systemd/user/el-serve.service with # hardening (NoNewPrivileges, ReadOnlyPaths=, ProtectSystem=strict). el serve --install-service # idempotent ./install.sh --with-serve # one-step: install + enable at bootstrap loginctl enable-linger $USER # survive reboots even when not logged in el serve --uninstall-service # reverse # Standalone YARA sweep over an existing case (auto-generates rules from iocs.json) el hunt /opt/EL/cases/wkstn-01 el hunt /opt/EL/cases/wkstn-01 --rules /opt/signature-base/yara/ # Memory timeline across multiple RAM-snapshot cases (Roussev & Quates # 2012 M57 Case-2 methodology): diff each snapshot's module inventory # against a baseline + against the previous snapshot to reveal what # executables / DLLs / drivers entered or left memory between snapshots. el timeline-memory /opt/EL/cases/host-day1 /opt/EL/cases/host-day3 \ --baseline /opt/EL/cases/host-baseline-disk el timeline-memory /opt/EL/cases/srl-*-memory # earliest becomes baseline # Browse the findings ledger el ledger /opt/EL/cases/wkstn-01 # Capture a host-state snapshot for chain of custody (any time) el provision-snapshot --label pre-incident # Verify a sealed case has not drifted since coordinator-DONE el seal-verify /opt/EL/cases/wkstn-01 # Query the cross-case knowledge store (~/.el/knowledge.sqlite) el knowledge stats el knowledge lookup 8.8.8.8 el knowledge lookup evil.example.com # Atomic Red Team coverage harness — for each ATT&CK technique mapped in # tests/atomic/expectations/coverage_map.yaml, run EL against a per-atomic # fixture and assert the corresponding hypothesis (or claim-substring) fires. # Use this to validate every new detector you add: drop a fixture, append # the YAML mapping, re-run. make atomic-validate ### Optional integrations (env-var configured) # Timesketch push — when --timeline is enabled, EL can upload the .plaso # storage to a Timesketch sketch named after the case (Apache-2.0). # Opt-in: set the URL and either a token or a username/password pair. export EL_TIMESKETCH_URL=https://timesketch.example.org export EL_TIMESKETCH_TOKEN= # preferred # or export EL_TIMESKETCH_USERNAME=alice export EL_TIMESKETCH_PASSWORD=$(pass timesketch/alice) # (export EL_TIMESKETCH_VERIFY=0 to disable TLS verification for self-signed) el investigate /cases/ --timeline # auto-pushes when set # CAPE Sandbox client — submit suspicious binaries from /exports/ to # a configured CAPEv2 instance for dynamic analysis (Cuckoo successor). # Opt-in via env vars; without them, EL skips CAPE and continues. export EL_CAPE_URL=https://cape.internal.lab export EL_CAPE_TOKEN= # preferred # (export EL_CAPE_VERIFY=0 to disable TLS verification for self-signed) # Microsoft-Extractor-Suite (Invictus IR) — M365 / Entra ID forensic # acquisition (UAL, MailItemsAccessed, sign-ins, OAuth consents, inbox # rules). Requires pwsh + Microsoft-Extractor-Suite module (install.sh # handles both). Opt-in via tenant credentials. export EL_M365_TENANT_ID= export EL_M365_APP_ID= # preferred export EL_M365_APP_SECRET= # or (less secure): # export EL_M365_USERNAME=alice@contoso.onmicrosoft.com # export EL_M365_PASSWORD=$(pass m365/alice) # Tracee eBPF runtime capture — chains off live-linux-system evidence # kind. Captures syscall/file/network events for a bounded duration during # live-response collection. Default 60s; tune via env var. Requires root # + kernel ≥4.18 + BTF (modern SIFT 22.04+ supports it natively). export EL_TRACEE_DURATION=60 # seconds (5..600) sudo el investigate / # live-system mode # TI push — submit per-case STIX 2.1 bundle to OpenCTI / MISP at coordinator # DONE so the org's threat-intel platform sees EL findings without manual # transformation. Both can be configured simultaneously. export EL_OPENCTI_URL=https://opencti.internal.lab export EL_OPENCTI_TOKEN= # and / or: export EL_MISP_URL=https://misp.internal.lab export EL_MISP_KEY= # (export EL_MISP_VERIFY=0 to disable TLS verification for self-signed) # AI executive brief — the executive HTML/PDF carries an AI-generated # six-section brief above the deterministic Findings (what_happened / # what_was_taken / where_it_went / when_timeline / risk_implications / # confidence_and_limits). Two auth paths: # # Path 1 — direct API: export ANTHROPIC_API_KEY=sk-ant-... # console.anthropic.com el investigate /cases/ # brief renders inline # # Path 2 — defer to Claude Code (no API key required): el investigate /cases/ --defer-ai-brief # writes request file # then in a Claude Code session: # /el-ai-brief # skill fulfils request, # re-renders HTML+PDF # # Without either path, the deterministic single-paragraph digest renders. # The AI brief is non-court-admissible; the Findings, Conclusion, and # Recommendations sections of the report stay deterministic projections # of findings.sqlite either way. Each case workspace lives at `cases//`: cases// ├── manifest.json # input hashes + intake UTC + magic + case_dir ├── findings.sqlite # structured Findings ledger ├── graph.kuzu/ # per-case Kùzu graph (entities + edges) ├── iocs.json # extracted IOC catalog ├── ach_matrix.json # hypothesis × finding score matrix ├── transitions.json # coordinator state-machine trace ├── CLAUDE.md # case-scoped Claude Code briefing ├── analysis/ │ ├── forensic_audit.log # append-only event log │ ├── triage/ # tool outputs grouped by agent │ ├── memory_forensicator/ │ ├── threat_hunter/ │ └── … ├── exports/ # extracted artifacts ├── reports/ │ ├── report.md # human-readable report │ ├── findings.json # machine-readable Findings dump │ └── stix-bundle.json # STIX 2.1 (MISP-importable) ├── seal.json # per-file sha256 manifest + merkle root + sealed_utc + el_git_rev └── raw/ # working space A `cases/_archives/-.tar.gz` archive of the entire case dir (seal.json embedded) is also written at coordinator-DONE for off-host retention. `el seal-verify ` re-hashes everything and reports any drift. ## Cross-case institutional knowledge In addition to the per-case workspace, EL maintains a global `~/.el/knowledge.sqlite` store recording every IOC every case has ever extracted, with full provenance: `(value, ioc_type, case_id, observed_utc, agent, sealed)`. After IOC extraction in each new case, EL queries the store for prior observations from OTHER cases and emits suggestive `Cross-case overlap` Findings: These findings carry `confidence='low'` on purpose — they show the analyst when an indicator is being seen across investigations without auto-lifting any hypothesis. Forensic conclusions in case B must stand on case B's own findings; case A is context, not evidence. The store is updated atomically as part of every `el investigate` run; sealed cases flip `sealed=1` so the knowledge layer can distinguish provisional observations from hash-verified ones. ## The contract Every finding ships with mandatory provenance: { "finding_id": "01KPDWYY9AV2HZ7ZXZ55CHDG3B", "case_id": "wkstn-01", "agent": "memory_forensicator", "claim": "Hidden processes detected — 2 PID(s) in psscan but absent from pslist", "confidence": "high", "evidence": [{ "tool": "volatility3", "version": "2.27.0", "command": "vol -q -r json -f /cases/wkstn-01.img windows.psscan.PsScan", "output_sha256": "…", "output_path": "…/windows_psscan_PsScan.json", "extracted_facts": {"row_count": 169, "rc": 0, "hidden_pids": [214668, 215928]} }], "hypotheses_supported": ["H_PROCESS_INJECTION", "H_ROOTKIT"], "ach_score_delta": {"H_APT_ESPIONAGE": 3, "H_BENIGN_NO_INCIDENT": -3}, "red_review": { "status": "challenged", "challenger_notes": "[NO_EVIDENCE_NO_CLAIM] A single tool's output is not corroboration…", "disconfirming_checklist": ["Re-run the same plugin with a different symbol set or tool version", …] } } Three hard rules (Pydantic-enforced): 1. **No finding without `evidence[]`.** The schema rejects high/medium/low confidence with empty evidence. The only escape is `confidence="insufficient"`. 2. **`insufficient` is a first-class output.** Better than a guess. 3. **Reproducibility manifest** ships with every report — every Finding's evidence carries the exact command. `el report ` re-renders deterministically. ## Evidence provenance — the `Source.txt` convention Drop a `Source.txt` next to each evidence image (in the directory for directory inputs; in the parent dir for single-file inputs). EL parses it at intake time and persists the fields into `manifest.json` + the "Evidence Source" section of every generated report — so you never have to update the case table below by hand again. Recognised filenames (first match wins): `Source.txt`, `SOURCE.txt`, `SOURCE`, `PROVENANCE.txt`, `provenance.txt`. Format is `Key: Value` per line; recognised keys (case-insensitive) map to three canonical fields: | Field | Aliases accepted | |---|---| | `Name` | `Name`, `Title`, `Scenario` | | `Url` | `Url`, `URL`, `URI`, `Link` | | `Source` | `Source`, `Origin`, `Provider`, `Corpus` | Example (the one shipped with the LoneWolf USB): Name: "2018 Lone Wolf Scenario" Url: https://digitalcorpora.org/corpora/scenarios/2018-lone-wolf-scenario/ Source: Digital Corpora When present, the report header renders an `## Evidence Source` block above the Evidence Manifest with Name / Source / URL spelled out. Absent: nothing rendered, no error — the convention is opt-in. ## Validated on real evidence EL has been exercised end-to-end on the following real evidence types, with each case surfacing bugs that became permanent regression tests: | Sample | Type | Size | Result | |---|---|---:|---| | SANS Hackathon-2026 wkstn | Win memory | 3 GB | H_APT_ESPIONAGE +3, 2 hidden processes detected | | SANS Hackathon-2026 dc | Win Server memory | 5 GB | Vol3 symbol mismatch surfaced as actionable; honest "insufficient" output (with our fix to score insufficient findings as neutral) | | 2020 Jimmy Wilson FTK image | E01 disk (NTFS) | 296 MB / 890 MB raw | Full chain: ewfmount → mmls → fls → mactime → mount + extract → WindowsArtifactAgent ran 4 EZ Tool parsers | | Charlie 2009 (XP-era) memory | MDD memory dump | 2 GB | H_APT_ESPIONAGE +19 (gap +9), credential-access carve-out flagged 10 RWX regions across lsass/winlogon/csrss; 28 dumped regions for offline RE | | FOR508 Stark Research Labs nrom | Paired memory + 9.7 GB E01 + baseline image | ~15 GB | Memory: H_APT_ESPIONAGE +25 with full attack chain via Memory Baseliner diff (PsExec → spinlock.exe Meterpreter, Mnemosynei386.sys driver, dllhost\svchost disguise). Disk: H_APT_ESPIONAGE +20 with 7 disk anomalies independently corroborating the memory finding | | Malware-Traffic-Analysis pcaps | Hancitor / Trickbot / Qakbot / Cobalt Strike | 5–40 MB each | Family fingerprint library attributes Hancitor (`/8/forum.php` URI) and Trickbot (gtag check-in pattern) directly from network traffic | | Malware-Traffic-Analysis corpus sweep | ~2000 pcaps (2013–2025) | ~50 GB total | Long-tail rarity bucketing validated in production; cross-case IOC knowledge store populated with 2000+ pcap case_ids | | BelkaCTF Kidnapper | Linux E01 (ext4) | 890 MB | `LinuxForensicator` + `ext4` mount; 12 /etc + 22 cron + 204 systemd services extracted; clean baseline (no malicious history patterns) | | BelkaCTF macOS Big Sur | macOS APFS filesystem tree | ~40 GB | `MacOSForensicator` + `fsapfsmount` APFS mount; 8 /etc_core + 3 SSH + 2 system launch plists + 1 KnowledgeC + 1 Quarantine + 3 Safari — clean baseline, no hits | | BelkaCTF Android | Extracted filesystem tree | ~30 GB | `AndroidForensicator` detected Magisk root + com.topjohnwu.magisk sideloaded via packageinstaller + WhatsApp presence — 3 detector hits | | BelkaCTF iPhone SE (iOS 14.3) | Extracted filesystem tree | ~200 GB | `IOSForensicator` pulled 63 app Info.plists + 105 bundle metadata + SMS/AddressBook/CallHistory/KnowledgeC/Health DBs; 18 encrypted-messenger / privacy-tool apps detected (Signal, Telegram, Wickr Enterprise, ProtonMail, Tutanota, Onion Browser, KeepSafe, Burner, …) — end-to-end in 1m39s after the intake Merkle-hash perf fixes | | [NPS M57-Jean](https://digitalcorpora.org/corpora/scenarios/m57-jean/) | NTFS E01 multi-part (Windows XP) | 3 GB | **EL arrived at the canonical answer neither [Basilmellow](https://github.com/Basilmellow/Autopsy-M57-Linux-Forensics) nor [jynxora](https://github.com/jynxora/M57-Jean-Case-Analysis) reached**: BEC / pretexting exfil (H_BEC_ACCOUNT_TAKEOVER score **51, gap +38** over runner-up H_INSIDER_EMAIL_EXFIL (13) on current `main`; the exact ACH score drifts with the `~/.el/knowledge.sqlite` corpus state — rarity-bucketing demotes IOCs as more cases accrue — so a fresh run reproduces the *ranking + canonical answer*, not the score to the point). Full story reconstructed: (1) attacker sent inbound email spoofing `alison@m57.biz` from `tuckgorge@gmail.com` (2 subjects: "Thanks!" + "Please send me the information now"), (2) Jean replied with `1_m57biz.xls (291840B)` attached, (3) bonus anti-forensic cleanup (15 zero-size + 15 zero-timestamp Windows system binaries — `auditusr.exe`, `pdh.dll`, `ciadmin.dll`), (4) 4778 IE5 cache records parsed including 24 `__utm` tracker-sync session-hijack artefacts. The per-finding `[finding_id]` citations + competing-hypothesis narrative render in `case.html` end-to-end | | [Digital Corpora — 2018 Lone Wolf Scenario](https://digitalcorpora.org/corpora/scenarios/2018-lone-wolf-scenario/) | Paired NTFS E01 (9-part, 13 GB) + Windows memory (18 GB) + pagefile (3 GB) | ~34 GB total | Disk: H_APT_ESPIONAGE score 21 · Cobalt Strike family fingerprint in `domain.txt` (`__utm.gif` Malleable-C2) · multi-technique lateral-movement chain on 2018-04-04 (PS-remoting + WMI event-consumer + service install) · 64 execution-corroborated findings · 161 prefetch + 146 EVTX + Amcache + SRUM extracted · new anti-forensics detectors fired (zero-size + zero-timestamp Windows system binaries) · 233-node Kùzu graph (1 Host + 71 Process + 154 File + 7 Event). Memory: H_C2_BEACONING score 11 · 4 Netscan beacon patterns to Azure IPs port 443 (`13.89.184.76 ×52`, `52.176.102.108 ×17`) · process-tree anomaly on explorer.exe · 19 cross-case knowledge hits linking LoneWolf memory IOCs to 14 prior Qakbot / Valak / Ursnif / Icedid / Ta551 pcap campaigns in the Layer-3 knowledge DB | Across these cases, EL surfaced 40+ bugs that are now locked in as regression tests — vol3 PATH inside venv subprocess, EVF vs EWF magic typo, FUSE-inside-FUSE mount target, IOC false-positives across 6 distinct categories (timestamps, version strings, X.509 OID labels, crypto curve constants, file-extension TLDs, Windows internals), empty-pslist hidden-process false flag, ACH scoring tool-failure messages, Memory Baseliner vol3-API drift, no no-partition extraction, no disk-side hypothesis scoring, triage `rglob` over iOS HGFS mounts, intake Merkle-hash dominated by per-file content reads on mobile trees, `_h_ransomware` substring match on "encrypted-messenger" (fixed with ransom-note phrase tightening), APFS dispatch gated on `fls` success (iOS returns 0 rows on APFS — fix: run extraction regardless). ## Analyst web view `el report --html` produces a single self-contained `reports/case.html` that opens directly in any modern browser (`file://` — no CDN, no framework, no build step, works inside a sealed `tar.gz` archive). Rolled out in four tiers per [docs/web-view-design.md](./docs/web-view-design.md): 1. **Static render** — executive summary, ACH ranking as horizontal bars, **chronological timeline** of findings, **Most Diagnostic Findings** (Heuer — highest ACH score-delta spread), **ACH consistency matrix** (finding × hypothesis grid), findings grid filterable by agent + confidence, per-finding detail drawer with evidence sha256s, extracted-facts, ACH Δ, and the disconfirming checklist from the Red Reviewer, IOC table, ATT&CK table. Deep-linkable by finding_id: `case.html#01KPMZC32QYA976TVHC026F5K0`. 2. **Attack-chain graph** — SVG force-directed layout of the per-case Kùzu substrate (Host / User / Process / File / IPAddress / Domain / Hash / NetworkFlow / Event nodes, 13 edge types). Pan + zoom + click-to-drawer; degree-capped at 500 nodes so huge graphs (scan-and-probe pcaps sit at 48k+) don't blow up the browser. 3. **ATT&CK coverage heatmap** — technique counts grouped by MITRE tactic, heat-coloured by finding count. 104 EL-emitted technique IDs mapped to primary tactics. Plus **Diamond Model** projection (Adversary / Capability / Infrastructure / Victim) for the ACH-leading hypothesis. 4. **Live-update mode** — `el report --html --watch` re-renders on every `findings.sqlite` change. Open `case.html?watch=3` in a browser for a 3-second auto-reload tick with a "LIVE" badge in the header. Matches the design doc's "static-served, no websockets" constraint so nothing new has to run beyond the local shell. ## Why this design - **No sycophancy, no false positives** — Red Reviewer is non-optional. The rule-based challenger always runs (deterministic baseline). The LLM challenger augments when an `ANTHROPIC_API_KEY` is set; their results merge with severity-bias toward "challenged". - **Tool output IS evidence** — Agents are Python orchestration around vetted CLI tools. We do NOT use an LLM to "read" event logs or parse process trees; deterministic parsers exist. LLMs reason about prioritisation and falsification, not extraction. - **Hypothesis-driven, not playbook-driven** — ACH puts ≥3 competing hypotheses on the table for every case, including the null (`H_BENIGN_NO_INCIDENT`). A finding's diagnostic value is the variance of its scores across hypotheses (Heuer's standard). - **Locard as data model** — the per-case Kùzu graph stores `Host`, `User`, `Process`, `File`, `RegistryKey`, `IPAddress`, `Domain`, `Hash`, `NetworkFlow`, `Event` nodes with edges like `EXECUTED`, `WROTE`, `CONNECTED_TO`, `CHILD_OF`, `RESOLVED_TO`, `AUTHENTICATED_AS`. - **Chain of custody first** — read-only on `/cases/`, `/mnt/`, `/media/`; all derived data goes to `analysis/`, `exports/`, `reports/`; UTC everywhere; SHA-256 manifests for inputs, evidence outputs, and provisioning snapshots. ## Status - **3,178 tests passing (89 skipped); `make test` runs them in ~10 minutes.** - 34 specialist agents · 140+ skill primitives · 33 case-level hypotheses with deterministic scorers · 105 ATT&CK technique → tactic mappings · 21 malware family fingerprints · 9 disk anomaly patterns - Validated end-to-end on 12 evidence types: Windows memory (workstation + DC) · NTFS E01 disk · paired memory+disk+baseline · malware-traffic pcaps (~2000-pcap corpus sweep) · MDD-format XP memory · Linux ext4 · macOS APFS · Android filesystem tree · iOS 14 filesystem tree · AWS CloudTrail JSON · Azure Entra sign-in / M365 UAL exports · multi-host SOC log corpus (Win Event XML / eCAR / Zeek JSON / Cisco ASA / Snort / syslog, fanned out per host). - Self-contained HTML case view (`el report --html`) covers all four design-doc tiers (static render, attack-chain graph, ATT&CK heatmap + Diamond Model, `--watch` live-update). - All cases sealed (sha256 manifest + tar.gz archive + `seal-verify` CLI); all IOCs recorded into `~/.el/knowledge.sqlite` for cross-case retention (2000+ pcap cases + memory + disk cases in the current knowledge DB). ## Author Created by **Murat Cakir**, [GSE #185](https://www.giac.org/certified-professional/Murat-Cakir/154250) — [LinkedIn](https://tr.linkedin.com/in/cakirm). ## License EL is licensed under the **Apache License, Version 2.0**. See [LICENSE](./LICENSE) for the full text. Apache 2.0 is a permissive license: you may use, modify, and redistribute EL in any product (commercial or non-commercial) provided you preserve the copyright + license notices and mark any changes you make. Apache 2.0 also grants an express patent license from every contributor to every user — important for a DFIR tool that touches techniques some vendors hold patents on. ### Third-party dependency license notices Every pip dependency EL pulls in is permissively licensed, with one flagged exception documented below for full disclosure. | Dependency | License | How EL uses it | |---|---|---| | `pydantic` | MIT | Finding-schema validation | | `kuzu` | MIT | Per-case entity-graph store | | `typer`, `rich` | MIT | CLI + terminal output | | `python-ulid` | MIT | finding_id generator | | `volatility3` | Volatility Software License v1.0 (MIT-compatible) | Memory forensics | | `anthropic` | MIT | Optional LLM Red Reviewer (only when `ANTHROPIC_API_KEY` is set) | | `stix2` | BSD-3-Clause | STIX 2.1 import + export | | `regipy` | MIT | BAM/DAM registry decoding | | `pefile` | MIT | PE structural deep-dive | | `oletools` (olevba + rtfobj) | BSD-2-Clause | Office document deobfuscation | | `ppdeep` | LGPL-3.0 | ssdeep fuzzy hashing (library API, not linked) | | `imagehash` | BSD-2-Clause | Perceptual image hashing (stego-carrier detector) | | **`scapy`** | **GPL-2.0** | **pcap parsing in NetworkAnalyst — flagged, see note below** | **`scapy` (GPL-2.0) — explicit flag.** Scapy is the only non-MIT/BSD/ Apache-family dependency. EL imports scapy's public API (no forking of its source, no static linking) and uses it in a single wrapper module (`el/skills/scapy_pcap.py`) with normal Python function calls; the combined work is distributed under Apache-2.0 while scapy retains its GPL-2.0 grant. This is consistent with how other Apache-2.0 projects (e.g. the Zeek control surface) ship scapy helpers. Operators who need a GPL-free installation can remove `scapy` from `pyproject.toml`'s `dependencies` list; `NetworkAnalyst` falls back to Zeek-only pcap replay (Zeek is BSD-3-Clause) and emits `confidence="insufficient"` only on DNS/TLS-SNI extraction, which the Zeek path fully covers. No runtime dependency on scapy exists outside `el.skills.scapy_pcap` — grep the repo to verify. Non-Python tools invoked via subprocess (Sleuth Kit / EWF tools / Plaso / bulk_extractor / EZ Tools / yara / evtexport / msiecfexport / cryptsetup / ewfmount / fsapfsmount / nfdump / journalctl) are installed independently on the SIFT Workstation and are governed by their own licenses (GPL-2 / CPL / IBM CPL / BSD / Apache / etc.). EL does not redistribute any of them — it only calls them via `subprocess` with list-form arguments. Operators are responsible for the license terms of the host SIFT image.
