# TiredVPN
[](https://github.com/tiredvpn/tiredvpn/actions/workflows/ci.yml)
[](https://github.com/tiredvpn/tiredvpn/releases/latest)
[](https://hub.docker.com/r/tiredvpn/tiredvpn)
[](https://goreportcard.com/report/github.com/tiredvpn/tiredvpn)
[](LICENSE)
[](go.mod)
**Related repositories:** [tiredvpn/tiredvpn-android](https://github.com/tiredvpn/tiredvpn-android) — Android client
## What is TiredVPN?
TiredVPN is a censorship-resistant VPN that uses multiple bypass strategies to
establish and maintain connectivity in networks with active Deep Packet
Inspection (DPI). Instead of relying on a single obfuscation technique, it
implements an adaptive strategy engine that automatically selects the best
transport based on current network conditions.
The system probes available strategies, ranks them by latency and reliability,
and falls back to alternatives mid-session if the active strategy gets blocked.
This makes it effective against sophisticated filtering systems like TSPU
(Russia), GFW (China), and similar DPI infrastructure.
Key design goals:
- **Resilience** - no single point of failure; if one strategy is blocked,
the client seamlessly switches to another.
- **Stealth** - traffic patterns are morphed to resemble legitimate services
(video streaming, CDN traffic, HTTPS browsing).
- **Performance** - multiplexed connections via smux, QUIC transport, and
adaptive RTT masking minimize overhead.
## Features
- **20+ DPI bypass strategies** with automatic selection and mid-session fallback
- **QUIC and TLS transports** with Salamander padding and SNI fragmentation
- **REALITY protocol** - impersonates legitimate websites with near-perfect TLS fingerprints
- **HTTP/2 steganography** - hides tunnel data inside real HTTP/2 frames
- **Traffic morphing** - statistically matches traffic patterns of popular services
- **Geneva engine** - country-specific packet manipulation rules (Russia, China, Iran, Turkey)
- **Multiplexed connections** via smux for efficient stream management
- **TUN mode** for full system traffic tunneling
- **SOCKS5 and HTTP proxy** modes
- **Port hopping** with random, sequential, and Fibonacci strategies
- **IPv6 transport** with dual-stack support and automatic fallback
- **Encrypted Client Hello (ECH)** to hide SNI from DPI
- **Post-quantum cryptography** (ML-KEM-768 + ML-DSA-65)
- **Multi-hop routing** through chained servers
- **Prometheus-compatible metrics** endpoint
- **Android integration** via JNI (c-shared build mode)
- **Docker support** with multi-stage builds
- **Client management** with Redis backend and REST API
- **QR code generation** for mobile client provisioning
## How TiredVPN Compares
| Feature | TiredVPN | Xray/VLESS | sing-box | Outline |
|---------|----------|------------|----------|---------|
| Bypass strategies | 20+ | 3–5 | 5–8 | 1–2 |
| Adaptive fallback | ✅ Mid-session | ❌ | Partial | ❌ |
| TSPU research | [Daily reports](reports/) | ❌ | ❌ | ❌ |
| Post-quantum crypto | ✅ ML-KEM-768 | ❌ | ❌ | ❌ |
| Geneva engine | ✅ | ❌ | ❌ | ❌ |
| RTT masking | ✅ | ❌ | ❌ | ❌ |
| ICMP fallback | ✅ | ❌ | ❌ | ❌ |
| Traffic morphing | ✅ | ❌ | ❌ | ❌ |
| Android app | ✅ Native | Third-party | Third-party | ✅ |
| License | AGPL-3.0 | MPL-2.0 | GPL-3.0 | Apache-2.0 |
## Quick Start
### Install
Download the latest binary for your platform:
curl -LO https://github.com/tiredvpn/tiredvpn/releases/latest/download/tiredvpn-linux-amd64.tar.gz
tar xzf tiredvpn-linux-amd64.tar.gz
sudo mv tiredvpn-linux-amd64 /usr/local/bin/tiredvpn
Available platforms: `linux-amd64`, `linux-arm64`. Other installation
methods are described in the [Docker](#docker) and
[Building from Source](#building-from-source) sections below.
Kubernetes via Helm (server and/or client from a single release):
helm install my-tiredvpn oci://ghcr.io/tiredvpn/charts/tiredvpn --version 0.1.0 \
-f my-values.yaml
See [deploy/helm/tiredvpn/README.md](deploy/helm/tiredvpn/README.md) for values, examples, and TLS/auth/Redis/HPA options.
### Generate a shared secret
openssl rand -hex 32
### Generate TLS certificates
For testing, create a self-signed certificate:
openssl req -x509 -newkey ec -pkeyopt ec_paramgen_curve:prime256v1 \
-days 365 -nodes -keyout server.key -out server.crt \
-subj "/CN=your-server.com"
For production, use [Let's Encrypt](https://letsencrypt.org/) with certbot:
sudo certbot certonly --standalone -d your-server.com
# Certificates will be at:
# /etc/letsencrypt/live/your-server.com/fullchain.pem
# /etc/letsencrypt/live/your-server.com/privkey.pem
### Server
tiredvpn server \
-listen :443 \
-cert server.crt \
-key server.key \
-secret
The server listens on both TCP (TLS) and UDP (QUIC) by default. It serves a
fake website to unauthenticated visitors, making it indistinguishable from a
normal HTTPS server.
### Client (SOCKS5 proxy)
tiredvpn client \
-server your-server.com:443 \
-secret \
-listen 127.0.0.1:1080
This starts a local SOCKS5 proxy on port 1080. Point your browser or
applications to `socks5://127.0.0.1:1080`.
### Client (full VPN / TUN mode)
sudo tiredvpn client \
-server your-server.com:443 \
-secret \
-tun \
-tun-routes 0.0.0.0/0
This creates a TUN interface and routes all traffic through the VPN.
## Configuration
TiredVPN is configured entirely via CLI flags. Run `tiredvpn server -help` or
`tiredvpn client -help` for the full list.
### Server flags
| Flag | Default | Description |
|------|---------|-------------|
| `-listen` | `:443` | IPv4 listen address |
| `-listen-v6` | `[::]:995` | IPv6 listen address |
| `-cert` | `server.crt` | TLS certificate file |
| `-key` | `server.key` | TLS private key file |
| `-secret` | | Shared secret (single-client mode) |
| `-redis` | | Redis address for multi-client mode |
| `-api-addr` | `127.0.0.1:8080` | REST API for client management |
| `-ip-pool` | | CIDR for TUN client IP assignment |
| `-port-range` | | Multi-port listening (e.g. `47000-47100`) |
| `-no-quic` | `false` | Disable QUIC/UDP listener |
| `-upstream` | | Upstream server for multi-hop |
| `-fake-root` | `./www` | Directory served to unauthenticated visitors |
| `-debug` | `false` | Verbose logging |
### Client flags
| Flag | Default | Description |
|------|---------|-------------|
| `-server` | | Remote server address (required) |
| `-secret` | | Shared secret (required) |
| `-listen` | `127.0.0.1:1080` | Local SOCKS5/HTTP proxy address |
| `-tun` | `false` | Enable TUN mode (full VPN) |
| `-tun-routes` | | Routes to tunnel (e.g. `0.0.0.0/0`) |
| `-quic` | `false` | Enable QUIC transport |
| `-strategy` | | Force a specific strategy |
| `-port-hop` | `false` | Enable port hopping |
| `-ech` | `false` | Enable Encrypted Client Hello |
| `-pq` | `false` | Enable post-quantum crypto |
| `-rtt-masking` | `false` | Hide proxy timing signature |
| `-prefer-ipv6` | `true` | Prefer IPv6 transport |
| `-fallback` | `true` | Mid-session strategy fallback |
| `-benchmark` | `false` | Run strategy latency benchmark |
### Client management
# Add a client (multi-client mode with Redis)
tiredvpn admin add -api http://127.0.0.1:8080 -server vpn.example.com:443
# List clients
tiredvpn admin list -api http://127.0.0.1:8080
# Delete a client
tiredvpn admin delete -api http://127.0.0.1:8080 -id
# Generate QR code for mobile app
tiredvpn admin qr -server vpn.example.com:443 -secret
## Docker
Pre-built images are available on Docker Hub. Platforms: `linux/amd64`, `linux/arm64`.
| Tag | Description |
|-----|-------------|
| `latest` | Latest stable release |
| `1.0.0` | Pinned version |
| `edge` | Latest main branch build |
### Run the server
docker run -d \
--name tiredvpn-server \
-p 443:443/tcp \
-p 443:443/udp \
-v /path/to/certs:/certs:ro \
tiredvpn/tiredvpn:latest \
server -listen :443 \
-cert /certs/server.crt \
-key /certs/server.key \
-secret
### Docker Compose
curl -O https://raw.githubusercontent.com/tiredvpn/tiredvpn/main/docker-compose.yml
TIREDVPN_SECRET= docker compose up -d
Or with a custom `docker-compose.yml`:
version: "3.8"
services:
tiredvpn-server:
image: tiredvpn/tiredvpn:latest
ports:
- "443:443/tcp"
- "443:443/udp"
volumes:
- ./certs:/certs:ro
command:
- "server"
- "-listen"
- ":443"
- "-cert"
- "/certs/server.crt"
- "-key"
- "/certs/server.key"
- "-secret"
- "${TIREDVPN_SECRET}"
- "-redis"
- "redis:6379"
depends_on:
- redis
restart: unless-stopped
redis:
image: redis:7-alpine
volumes:
- redis-data:/data
restart: unless-stopped
volumes:
redis-data:
### Build locally
docker build -t tiredvpn .
## Building from Source
### Requirements
- Go 1.26 or later
- Linux, macOS, or Windows (TUN mode requires Linux)
### Build
git clone https://github.com/tiredvpn/tiredvpn.git
cd tiredvpn
make build
Or directly with Go:
go build -o tiredvpn ./cmd/tiredvpn/
### Cross-compile for Linux (amd64)
make build-linux
### Cross-compile for Android (arm64)
make build-android
### Run tests
make test
## Strategies
TiredVPN includes an adaptive strategy engine that automatically selects the
best transport. Each strategy targets a different aspect of DPI evasion.
| ID | Name | Description |
|----|------|-------------|
| `quic_salamander` | QUIC Salamander | QUIC over UDP with Salamander padding (default, hardest to fingerprint) |
| `quic` | QUIC Tunnel | QUIC transport with version spoofing (draft-29 to bypass TSPU) |
| `reality` | REALITY Protocol | Impersonates legitimate websites with authentic TLS fingerprints |
| `http2_stego` | HTTP/2 Steganography | Hides data inside HTTP/2 frames with NaiveProxy-style padding |
| `websocket_padded` | WebSocket Salamander | WebSocket transport with Salamander obfuscation padding |
| `http_polling` | HTTP Polling | Short-lived HTTP/1.1 requests (meek-style), evades long-connection detection |
| `morph_*` | Traffic Morphing | Reshapes traffic to match video streaming profiles (Yandex, VK) |
| `confusion_*` | Protocol Confusion | Makes packets appear as DNS/HTTP/SSH/SMTP over TLS |
| `geneva_*` | Geneva Engine | Country-specific packet manipulation (Russia TSPU, China GFW, Iran, Turkey) |
| `antiprobe` | Anti-Probe | Server masquerades as normal website; reveals tunnel only to authenticated clients |
| `state_exhaustion` | State Exhaustion | Floods DPI state table with decoys to trigger fail-open mode |
| `mesh_relay` | Mesh Relay | Routes through relay nodes in regions with lighter filtering |
| `icmp_tunnel` | ICMP Tunnel | Backup tunnel over ICMP Echo (stealth mode, requires CAP_NET_RAW) |
The strategy engine supports:
- **Automatic probing** - tests all available strategies and ranks by latency
- **Circuit breakers** - disables failing strategies after configurable threshold
- **Mid-session fallback** - switches strategy without dropping the connection
- **Periodic re-probing** - re-evaluates blocked strategies on a timer
- **Benchmarking** - `tiredvpn client -benchmark` to test all strategies
## Architecture
cmd/tiredvpn/ CLI entrypoint (server, client, admin)
internal/
server/ Server-side connection handling, TLS/QUIC listeners
client/ Client-side proxy, TUN, strategy orchestration
strategy/ DPI bypass strategies and adaptive engine
tun/ TUN device management
mux/ smux multiplexer integration
tunnel/ Tunnel abstractions
proxy/ SOCKS5 and HTTP proxy
tls/ TLS utilities and uTLS fingerprinting
evasion/ Low-level evasion primitives
geneva/ Geneva packet manipulation engine
porthopping/ Port hopping logic
multiport/ Multi-port listener
pool/ IP address pool for TUN clients
metrics/ Prometheus metrics collector
padding/ Traffic padding utilities
protect/ Android VpnService socket protection
control/ Android control socket protocol
config/ Configuration types
log/ Structured logging
benchmark/ Strategy benchmarking
ktls/ Kernel TLS offload
## Documentation
Full documentation is available in the [docs/](docs/) directory:
- [Getting Started](docs/getting-started.md)
- [Server Reference](docs/server.md)
- [Client Reference](docs/client.md)
- [DPI Bypass Strategies](docs/strategies.md)
- [Deployment Guide](docs/deployment.md)
- [Security Model](docs/security.md)
- [Monitoring](docs/monitoring.md)
## License
TiredVPN is licensed under the [GNU Affero General Public License v3.0](LICENSE).
标签：EVTX分析
