cristiancmoises/zupt
GitHub: cristiancmoises/zupt
一个采用纯 C11 编写、集成后量子密钥封装与硬件加速加密的跨平台备份压缩工具，提供端到端完整性保护与抗量子攻击能力。
Stars: 12 | Forks: 1
**Compress everything. Trust nothing. Encrypt always.**
Backup compression with hardware-adaptive codec selection, AES-256 authenticated encryption, post-quantum key encapsulation, and full-disk backup. Pure C11, zero dependencies, ~13,000 lines. Builds and runs on x86_64, aarch64, armhf, ppc64le, s390x, and riscv64.
## 为什么选择 Zupt
- **Hardware-adaptive codec** — auto-detects AVX2/NEON at runtime and selects the best codec: VaptVupt (LZ77 + tANS + SIMD decode) on capable hardware, Zupt-LZHP on everything else. Override with `--vv` or `--lzhp`.
- **Post-quantum encryption** — `--pq` mode uses ML-KEM-768 + X25519 hybrid KEM (same approach as Signal and iMessage). Protects against "harvest now, decrypt later" quantum attacks.
- **AES-NI hardware acceleration** — AES-256-CTR via Jasmin-verified assembly with 4-block interleaved pipeline. Safe AVX detection with OSXSAVE/XCR0 validation — no SIGILL on any CPU. Falls back to C table-based AES on unsupported hardware.
- **Multi-threaded** — Compression and decompression both parallelized. `-t 0` auto-detects cores.
- **Full-disk backup** — `zupt disk backup` clones entire disks or partitions in one command. Sparse block detection skips zero regions, real-time progress bar, all encryption modes supported. Restore with byte-for-byte verification via per-block XXH64 checksums.
- **Encrypted backups in one command** — `zupt compress -p changeme backup.zupt ~/data/` — AES-256 + HMAC-SHA256, file names hidden.
- **Per-block integrity** — XXH64 checksum + HMAC-SHA256 per block. Wrong password rejected instantly.
- **Formally verified crypto** — 5 Jasmin assembly functions with constant-time proofs. 19 ACSL-annotated functions for Frama-C memory safety analysis.
- **Multi-architecture** — builds on x86_64, aarch64, armhf, ppc64le, s390x, riscv64. Jasmin CT crypto on x86_64, C fallback everywhere else. Any archive decompresses on any architecture.
- **Zero dependencies** — ML-KEM, X25519, Keccak, SHA-256, AES-256, HMAC, PBKDF2, VaptVupt codec — all pure C11. Builds with `gcc` or `cl` alone.
## 快速开始
### 快速安装
```
curl -fsSL https://short.securityops.co/zupt | bash
```
### 构建与安装
```
git clone https://github.com/cristiancmoises/zupt.git && \
cd zupt && \
make && \
sudo make install
```
### openSUSE 软件包
The [openSUSE for Innovators](https://en.opensuse.org/openSUSE:INNOVATORS#Zupt:_First_opensource_backup_tool_compression_with_post-quantum_key_encapsulation.) initiative offers Zupt within the [Diraq](https://en.opensuse.org/User:Cabelo/DiraQ) solution.
For 16.0:
```
zypper addrepo https://download.opensuse.org/repositories/home:cabelo:innovators/16.0/home:cabelo:innovators.repo
zypper refresh && zypper install zupt
```
### 基本用法
```
# 压缩（为您的硬件自动选择最佳编解码器）
zupt compress backup.zupt ~/Documents/
# 使用密码加密压缩
zupt compress -p "changeme" backup.zupt ~/Documents/
# 解压
zupt extract -o ~/restored/ backup.zupt
# 后量子加密备份
zupt keygen -o mykey.key
zupt keygen --pub -o pub.key -k mykey.key
zupt compress --pq pub.key backup.zupt ~/Documents/
zupt extract --pq mykey.key -o ~/restored/ backup.zupt
```
## 自动编解码器检测
Zupt v2.0.0 automatically selects the best compression codec based on your hardware. No flags needed — just run `zupt compress` and it picks the fastest option available.
| Architecture | SIMD Available | Default Codec | Decode Throughput |
|---|---|---|---|
| x86_64 + AVX2 | AVX2 inline SIMD | **VaptVupt** | ~2–3 GB/s |
| x86_64 (no AVX2) | Scalar | Zupt-LZHP | ~500 MB/s |
| aarch64 + NEON | NEON SIMD | **VaptVupt** | ~1–2 GB/s |
| armhf, ppc64le, s390x, riscv64 | Scalar | Zupt-LZHP | ~300–500 MB/s |
**Decompression is universal.** An archive created with VaptVupt on x86_64 extracts on aarch64 (using NEON or scalar decode), and vice versa. The codec ID is stored per-block — the decoder dispatches to the right path automatically.
Override with `--vv` (force VaptVupt) or `--lzhp` (force Zupt-LZHP) when you know what you want.
## VaptVupt 编解码器
VaptVupt is Zupt's high-performance compression codec. It combines LZ77 dictionary matching with tANS (table-based Asymmetric Numeral Systems) entropy coding and SIMD-accelerated decompression.
### 架构
```
Encoder: Hash-chain LZ77 → 5-byte multiply-shift hash, rep-match (3 recent offsets),
lazy-2 parsing, AVX2 match extension (32 bytes/cycle)
Entropy: Canonical Huffman | tANS | 4-way interleaved ANS | order-1 context model
Decoder: AVX2 inline SIMD copies, tiered by offset (32/16/8/overlap), safe-zone fast path
NEON SIMD on aarch64, scalar fallback on all architectures
```
### 三种模式
| Mode | CLI | Chain Depth | Entropy | Use Case |
|------|-----|-------------|---------|----------|
| Ultra-Fast | `-l 1` to `-l 3` | 4 | None | Speed priority, streaming |
| Balanced | `-l 4` to `-l 7` (default) | 48 | 4-way ANS | General backup data |
| Extreme | `-l 8` to `-l 9` | 256 | Order-1 context ANS | Maximum compression |
### 基准测试结果
Measured on the build host with a 1.9 MB mixed corpus (text, JSON, CSV, random binary). Each codec run once, wall-clock time via `clock_gettime(CLOCK_MONOTONIC)`. Reproduce with `zupt bench --compare`.
| Codec | Compress | Decompress | Ratio |
|-------|----------|------------|-------|
| **VaptVupt UF** | 63 MB/s | **298 MB/s** | 2.7:1 |
| **VaptVupt BAL** (default) | 18 MB/s | **268 MB/s** | 3.5:1 |
| **VaptVupt EXT** | 12 MB/s | **311 MB/s** | 3.5:1 |
| Zupt-LZHP (v1.x default) | 8 MB/s | 137 MB/s | 4.0:1 |
| Zupt-LZ | 28 MB/s | 348 MB/s | 3.3:1 |
| gzip -6 | 26 MB/s | 99 MB/s | 4.0:1 |
VaptVupt BAL decompresses **2× faster** than the previous Zupt-LZHP default and **2.7× faster** than gzip, while achieving competitive compression ratios. Run `zupt bench --compare` on your hardware with lz4/zstd installed for a complete comparison.
### 为什么选择 VaptVupt？
VaptVupt's architectural advantages over traditional Huffman-based codecs:
- **tANS entropy** — asymptotically optimal coding with single-instruction decode per symbol (vs Huffman's multi-step tree walk)
- **4-way interleaved ANS** — decodes 4 symbols per bitstream refill cycle, reducing refill overhead by 4×
- **AVX2/NEON SIMD decode** — inline 32-byte copies with tiered offset handling (no function-pointer dispatch). Falls back to scalar on unsupported hardware.
- **Rep-match** — checks 3 recent offsets before hash probe (O(1) vs O(chain_depth)), hits ~30% of matches. Saves 10–15 bits per repeated offset.
- **Order-1 context model** — captures byte-pair correlations in structured data (JSON, CSV, logs)
- **Adaptive window** trial-compresses at wlog=16 vs wlog=20, picks larger window only if ≥3% improvement
- **~4,200 lines** of pure C11 — auditable, portable, no external dependencies
## 后量子加密
`--pq` mode uses hybrid ML-KEM-768 + X25519 key encapsulation per NIST FIPS 203.
```
Public key → ML-KEM-768 Encaps + X25519 ECDH → hybrid shared secret
→ SHA3-512(ss ‖ transcript) → enc_key[32] + mac_key[32]
→ AES-256-CTR + HMAC-SHA256 per block
```
**Security model:** Secure if EITHER ML-KEM-768 (post-quantum) OR X25519 (classical) is secure.
**Password mode (`-p`) is NOT quantum-safe.** Use `--pq` for long-term protection.
## 全磁盘备份
Clone entire disks, partitions, or raw images with compression and encryption in one command.
### 快速开始
```
# 克隆分区（需要读取权限）
sudo zupt disk backup backup.zupt /dev/sda1
# 使用后量子加密克隆（最强）
zupt keygen -o mykey.key
zupt keygen --pub -o pub.key -k mykey.key
sudo zupt disk backup --pq pub.key backup.zupt /dev/nvme0n1p2
# 使用密码加密克隆
sudo zupt disk backup -p backup.zupt /dev/sda1
# 最大压缩（9 级，极端模式）
sudo zupt disk backup -l 9 backup.zupt /dev/sda1
# 恢复到设备或文件
sudo zupt disk restore backup.zupt /dev/sda1
sudo zupt disk restore --pq mykey.key backup.zupt /dev/sda1
```
### 工作原理
```
Source device → Read 4MB blocks → Sparse detection → Compress → Encrypt → Write .zupt
│ │ │
│ │ └─ AES-256-CTR + HMAC-SHA256
│ └─ VaptVupt/LZHP (auto-selected)
└─ Zero blocks stored as STORE (near-zero overhead)
```
Zupt reads the source device sequentially in 4MB chunks. Each block is checked for all-zero content (sparse detection uses 8-byte-wide comparison). Zero blocks are stored with codec `STORE` — effectively just the block header with no payload, saving both compression CPU time and archive space. Non-zero blocks are compressed with the selected codec and optionally encrypted. Per-block XXH64 checksums ensure byte-for-byte integrity on restore.
### 最佳实践
**Encryption hierarchy (strongest → fastest):**
| Mode | Command | Security Level | Speed Impact |
|------|---------|---------------|-------------|
| PQ Hybrid | `--pq pub.key` | Quantum-resistant + classical | ~5% overhead |
| Password | `-p` | AES-256, PBKDF2 600K iter | ~3% overhead |
| None | (default) | Integrity only (XXH64) | Fastest |
**Compression levels for disks:**
| Level | Mode | Best for | Typical ratio |
|-------|------|----------|--------------|
| `-l 1` to `-l 3` | Ultra-Fast | Live systems, NVMe (speed priority) | 1.5–2.5:1 |
| `-l 4` to `-l 7` | Balanced (default) | General partitions, ext4/NTFS | 2–5:1 |
| `-l 8` to `-l 9` | Extreme | Cold storage, archival backups | 3–10:1 |
**Operational guidance:**
- **Unmount before backup** for filesystem consistency. For live systems, use LVM snapshots or filesystem freeze: `fsfreeze -f /mnt/data && zupt disk backup ... && fsfreeze -u /mnt/data`.
- **Block devices require root** on Linux. Regular files (disk images, `.img`, `.raw`) do not.
- **Sparse-heavy disks** (freshly formatted, VMs with thin provisioning) compress extremely well — the sparse detector skips zero blocks at memory-copy speed with no compression overhead.
- **Verify after backup** with `zupt test archive.zupt` — checks every block's XXH64 checksum without extracting.
- **PQ encryption for long-term** — disk backups stored for years should use `--pq` to resist future quantum attacks. Generate one keypair, store the private key offline, distribute the public key.
- **Restore is non-destructive on files** — writing to a regular file creates/overwrites it. Writing to a block device overwrites the raw device. Double-check the target path before restoring to a device.
### 与其他工具的比较
| Feature | Zupt disk | dd + gzip | Clonezilla | partclone |
|---------|-----------|-----------|------------|-----------|
| Compression | VaptVupt/LZHP (adaptive) | gzip (fixed) | Multiple | Multiple |
| Encryption | AES-256 + PQ hybrid | None (pipe to gpg) | None | None |
| Sparse detection | Automatic | None | Filesystem-aware | Filesystem-aware |
| Per-block integrity | XXH64 per block | None | None | CRC32 |
| Single binary | ✓ (zero deps) | 2+ tools | ISO boot | Multiple |
| Post-quantum | ML-KEM-768 | — | — | — |
| Cross-platform | 6 architectures | ✓ | x86 only | Linux only |
## 多架构支持
Zupt builds and runs on all major architectures. The Makefile auto-detects the platform and enables the best available features.
| Feature | x86_64 | aarch64 | armhf | ppc64le | s390x | riscv64 |
|---------|--------|---------|-------|---------|-------|---------|
| Jasmin CT crypto | ✓ | C fallback | C fallback | C fallback | C fallback | C fallback |
| AES-NI hardware | ✓ (with AVX) | — | — | — | — | — |
| AVX2 SIMD decode | ✓ | — | — | — | — | — |
| NEON SIMD decode | — | ✓ | — | — | — | — |
| Default codec | VaptVupt | VaptVupt | LZHP | LZHP | LZHP | LZHP |
| All codecs decode | ✓ | ✓ | ✓ | ✓ | ✓ | ✓ |
Build for packaging (PIE, hardening flags):
```
make CFLAGS="-Wall -Wextra -O2 -std=c11 -fPIE -Iinclude -Isrc" LDFLAGS="-pie -Wl,-z,relro,-z,now"
make install DESTDIR=/buildroot
```
## 功能对比
| Feature | Zupt v2.1 | gzip | zstd | 7-Zip |
|---------|-----------|------|------|-------|
| Default codec | VaptVupt/LZHP (auto) | DEFLATE | FSE+Huffman | LZMA2 |
| Full-disk backup | **`zupt disk`** | — | — | — |
| Post-quantum encryption | **ML-KEM-768** | — | — | — |
| Password encryption | AES-256 + HMAC | — | — | AES-256 |
| AES-NI hardware accel | **Jasmin-verified** | — | — | — |
| Per-block integrity | XXH64 + HMAC | CRC32 | XXH64 | CRC32 |
| Multi-threaded compress | ✓ | — (pigz) | ✓ | ✓ |
| Multi-threaded decompress | **✓** | — | ✓ | ✓ |
| Formal verification | **Jasmin CT + ACSL** | — | — | — |
| mlock() key protection | ✓ | — | — | — |
| AFL++ fuzz harness | ✓ | — | ✓ | — |
| Multi-architecture | **6 arches** | ✓ | ✓ | ✓ |
| Zero dependencies | ✓ | ✓ | — | — |
| Codebase | ~12K lines | ~10K | ~75K | ~100K+ |
| License | MIT | GPL | BSD | LGPL |
## 安全性
```
Password mode: Password → PBKDF2-SHA256 (600K iter) → enc_key + mac_key
PQ hybrid mode: Public key → ML-KEM-768 Encaps + X25519 ECDH → enc_key + mac_key
Per-block: AES-256-CTR(enc_key, nonce ⊕ seq) + HMAC-SHA256(mac_key)
Key protection: mlock() prevents swap, buffer canaries detect overflow
Timing: Always-decrypt mitigation (no timing oracle on MAC failure)
AES dispatch: AVX+AES-NI check with OSXSAVE/XCR0 (no SIGILL on any CPU)
Verification: 5 Jasmin CT proofs, 19 ACSL contracts, 13 NIST/RFC test vectors
```
See [SECURITY.md](SECURITY.md) for threat model. See [AUDIT.md](AUDIT.md) for audit checklist.
## 用法
```
zupt compress [OPTIONS] 标签：AES-256, AES-NI, AVX2, C11, HMAC-SHA256, Jasmin, LZ77, ML-KEM, NEON, openSUSE, ppc64le, ProjectDiscovery, riscv64, s390x, SIMD, tANS, X25519, XXH64, 全磁盘备份, 加密, 压缩, 后量子加密, 备份, 安全备份, 客户端加密, 密钥封装, 并行压缩, 收获现在解密将来, 数据保护, 文件隐藏, 校验和, 混合密钥交换, 漏洞扫描器, 漏洞评估, 硬件加速, 硬件自适应编解码器, 稀疏块检测, 认证加密, 进度条, 量子安全, 防量子攻击, 零依赖
