# TetraMCP for Ghidra
TetraMCP is a unified [Model Context Protocol](https://modelcontextprotocol.io/) (MCP) server for [Ghidra](https://ghidra-sre.org/), providing AI agents with direct access to reverse engineering capabilities.
TetraMCP extends Ghidra's three core perspectives -- hex, disassembly, and debugging -- with a fourth: an LLM cognition layer delivered via MCP. The result is a single Ghidra extension that turns any MCP-compatible AI client into a reverse engineering assistant.
## Overview
TetraMCP integrates several key components:
1. **Native MCP Server**: Runs directly inside Ghidra via an embedded Jetty server. No Python bridges or external processes are required; it communicates via Streamable HTTP.
2. **Comprehensive Tooling**: Exposes 120+ tools across 25 categories, covering everything from decompilation and memory analysis to P-code emulation and AI-enhanced renaming.
3. **AI Integration Layer**: Optional built-in support for LLMs (Anthropic, OpenAI, or compatible) to automate tasks like function explanation, variable renaming, and commenting directly within the analysis context.
4. **Multi-Program Architecture**: Supports simultaneous analysis of multiple open binaries with isolated state management.
This architecture enables AI assistants to:
- Decompile, disassemble, and analyze binary code with low-level precision.
- Perform cryptographic constant detection and signature matching.
- Utilize P-code emulation for dynamic behavior inspection.
- Collaborate on complex reversing tasks using a shared context model for multi-agent systems.
- Automate tedious renaming and documentation tasks via integrated AI.
## Features
TetraMCP provides a comprehensive set of reverse engineering capabilities organized into logical categories:
### Advanced Program Analysis
### AI-Enhanced Capabilities
- **Automated Renaming**: Leverage LLMs to suggest meaningful names for functions and variables based on context.
- **Code Explanation**: Generate function summaries and save them directly as plate comments.
- **Line-by-Line Annotation**: Add detailed comments to decompiled code automatically.
- **Log-Based Analysis**: Recover function names automatically from debug logging calls.
### Extensive Tooling
- **Cryptographic Detection**: Scan for known constants (AES, SHA, MD5, etc.) using an embedded signature database.
- **P-code Emulation**: Step through code, inspect registers, and modify memory state.
- **External Tools**: Integration with `binwalk`, `YARA`, and specialized Go binary analysis.
- **Multi-Agent Collaboration**: Shared findings, task queues, and progress tracking for complex workflows.
# Installation
## Prerequisites
- [Ghidra](https://ghidra-sre.org/) (Version 12.0.4 or later)
- JDK 21
## Ghidra Plugin Installation
First, download the latest release ZIP or build from source (see below). Then, add the plugin to Ghidra:
1. Run Ghidra
2. Select `File` -> `Install Extensions`
3. Click the `+` button
4. Select the `TetraMCP-[version].zip` file
5. Restart Ghidra
6. Open a binary in CodeBrowser
7. Navigate to `File` -> `Configure` (plug icon) -> `Developer`
8. Check **TetraMcpPlugin** to enable it
# Client Setup
TetraMCP works with any MCP-compatible client that supports **Streamable HTTP transport**.
### Claude Desktop Configuration
Add the following to your `claude_desktop_config.json`:
{
"mcpServers": {
"tetramcp": {
"type": "http",
"url": "http://localhost:18489/mcp"
}
}
}
### Claude Code Configuration
Run the following command to add the server:
claude mcp add tetramcp --transport http http://localhost:18489/mcp
### Cursor Configuration
Create or edit `.cursor/mcp.json` in your project root:
{
"mcpServers": {
"tetramcp": {
"url": "http://localhost:18489/mcp"
}
}
}
## API Reference
TetraMCP organizes 120+ tools into logical namespaces.
### Program and Instance Management
- `program_info`: Program metadata (name, architecture, compiler, hashes).
- `instances_list`: List open programs.
- `instances_use`: Switch active program context.
### Function Analysis
- `functions_decompile`: Decompile to C with pagination.
- `functions_disassemble`: Assembly listing.
- `functions_rename`: Rename functions.
- `functions_find_undefined`: Discover undefined code.
### Memory and Data
- `memory_read`: Hex dump with ASCII.
- `memory_search_bytes`: Pattern search with wildcards.
- `data_list_strings`: List strings with regex filtering.
- `structs_create` / `structs_update_field`: Manage data structures.
### Analysis and AI
- `analysis_callgraph`: Generate call graphs.
- `analysis_cfg`: Control flow graphs.
- `ai_suggest_renames`: LLM-powered renaming suggestions.
- `ai_explain_function`: Auto-generate function summaries.
### Emulation
- `emulation_create`: Start a P-code emulator.
- `emulation_step`: Step execution.
- `emulation_get_state`: Inspect registers and memory.
### Multi-Agent
- `agents_add_finding`: Record analysis findings.
- `agents_get_next_task`: Coordinate workflow tasks.
## Example Session
Below is an example of how an AI assistant might interact with Ghidra using TetraMCP:
**User:**
Find the main function, explain what it does, and check for any cryptographic constants.
**Assistant:**
I'll start by locating the main function and analyzing it.
[Uses functions_list with filter "main"]
Found 'main' at address 0x00401000.
[Uses functions_decompile for 'main']
Retrieved decompiled code. The function initializes a socket and encrypts data before sending.
[Uses ai_explain_function for 'main']
LLM Explanation: This function serves as the entry point for the network handler. It allocates a buffer, initializes a cryptographic context, and enters a loop to process incoming data packets.
[Uses crypto_scan on the current program]
Cryptographic constants detected:
- AES S-Box at 0x00402000
- SHA-256 IV at 0x00402100
I have added a plate comment to 'main' with the generated explanation and identified the crypto constants used.
**User:**
Rename the buffer variable in main to 'packet_buffer' and check cross-references to the AES S-Box.
**Assistant:**
[Uses variables_rename in function 'main' old_name 'buffer' new_name 'packet_buffer']
Variable renamed successfully.
[Uses xrefs_to address 0x00402000]
Found 2 references to the AES S-Box:
- encrypt_data (0x00401150)
- decrypt_data (0x00401230)
The cryptographic functions have been identified. Would you like me to analyze the 'encrypt_data' function next?
# Configuration
Server and AI settings are configured in Ghidra under **Edit > Tool Options**.
### Server Settings (TetraMCP)
| Setting | Default | Description |
|---------|---------|-------------|
| Server Host | `127.0.0.1` | Bind address |
| Server Port | `18489` | HTTP port |
### AI Settings (TetraMCP.AI)
| Setting | Default | Description |
|---------|---------|-------------|
| AI Enabled | `false` | Enable AI-assisted analysis |
| AI Provider | `anthropic` | `anthropic` or `openai` |
| AI Model | `claude-sonnet-4-6` | Model name |
**Local Models (Ollama example):** Set Provider to `openai`, API URL to `http://localhost:11434/v1/chat/completions`, leave API Key empty, and set Model to your model name.
# Architecture
TetraMCP runs as a single Java codebase inside the Ghidra JVM, eliminating the need for bridge scripts or serialization boundaries.
MCP Client (Claude, Cursor, etc.)
|
| Streamable HTTP (:18489/mcp)
|
Jetty 12 (embedded HTTP server)
|
MCP Java SDK
|
Tool Providers (27 providers, 120+ tools)
|
Ghidra APIs (FlatProgramAPI, DecompInterface, etc.)
## Extending with Custom Tools
Implement `TetraMcpModule` and register via Java's `ServiceLoader`:
public class MyModule implements TetraMcpModule {
public String getName() { return "MyTools"; }
public List
getToolSpecifications(McpServerManager mgr) {
// Return tool definitions
}
}
# Building from Source
**Requirements:** JDK 21, Ghidra 12.0.4 or later.
export GHIDRA_INSTALL_DIR=/path/to/ghidra
./gradlew buildExtension
The extension ZIP is created in `dist/`.
# License
Apache License 2.0. See [LICENSE](LICENSE) for the full text.
# Acknowledgments
- [Ghidra](https://ghidra-sre.org/) by the National Security Agency
- [Model Context Protocol](https://modelcontextprotocol.io/) specification
- [MCP Java SDK](https://github.com/modelcontextprotocol/java-sdk)
