cdua-org/ReconSR
GitHub: cdua-org/ReconSR
Stars: 1 | Forks: 0
# ReconSR
░█▀█░█▀▀░█▀▀░█▀█░█▄░█░█▀▀░█▀█
░█▀▄░█▀▀░█░░░█░█░█░▀█░▀▀█░█▀▄
░▀░▀░▀▀▀░▀▀▀░▀▀▀░▀░░▀░▀▀▀░▀░▀
[](https://github.com/cdua-org/ReconSR/actions/workflows/ci.yml)
[](https://github.com/cdua-org/ReconSR/releases)
[](https://github.com/cdua-org/ReconSR/commits/main)
[](https://github.com/cdua-org/ReconSR/issues)
[](https://github.com/cdua-org/ReconSR)
[](https://github.com/cdua-org/ReconSR/wiki)
[](LICENSE)
ReconSR is an automated OSINT tool designed to provide cybersecurity researchers with a modular framework for mapping and analyzing complex digital footprints and attack surfaces.
## System Architecture
ReconSR moves beyond traditional flat-list enumeration by implementing a reactive, event-driven pipeline that recursively transforms discoveries into new investigative targets.
## Shared Module Utilities (`modules/utils`)
`modules/utils` contains reusable building blocks shared across intelligence modules. These packages are not dispatcher modules and do not expose reconnaissance functions directly; they centralize common concerns such as API key loading, shared constants, DNS record parsing, HTTP retry/status handling, module execution helpers, resolver/runtime settings, etc.
## Intelligence Modules (`modules/`)
### 1. Subdomain Hierarchy (`modules/subdomain_hierarchy`)
### 2. Advanced DNS Discovery (`modules/dns`)
### 3. Mail Identity Crypto (`modules/mailcrypto`)
### 4. WHOIS/RDAP (`modules/whois`)
### 5. Hunter.io Email Intelligence (`modules/hunterio`)
### 6. HaveIBeenPwned Data Breaches (`modules/haveibeenpwned`)
### 7. Certificate Transparency (`modules/domainsbycerts`)
### 8. HackerTarget Passive DNS (`modules/hackertarget`)
### 9. Anubis DB (`modules/anubis`)
### 10. IPv4 Deobfuscation (`modules/ipv4ambiguous`)
### 11. IP Intelligence (`modules/ip_metadata`)
### 12. IPinfo Intelligence (`modules/ipinfo`)
### 13. AbuseIPDB Reputation (`modules/abuseipdb`)
### 14. IP2Location Local Intelligence (`modules/ip2location`)
### 15. MaxMind Local Intelligence (`modules/maxmind`)
### 16. ASN Intelligence (`modules/asn_metadata`)
### 17. Shodan Intelligence (`modules/shodan`)
### 18. VirusTotal Intelligence (`modules/virustotal`)
### 19. Vulnerability Lookup (`modules/vuln_lookup`)
### 20. LeakIX Intelligence (`modules/leakix`)
## Security by Design
While ReconSR currently operates as a local CLI tool, its architecture is built with enterprise-grade security primitives to ensure a safe transition to future multi-tenant SaaS or Web environments:
* **Zero Trust Module Execution:** The core engine inherently distrusts external modules. The `Processor` strictly enforces the "Black Box" contract, validating not only the syntax of incoming intelligence but also verifying that modules only return data for explicitly requested functions. Rogue or hijacked modules attempting to inject unsolicited data are automatically rejected.
* **Strict Input Sanitization:** All entities (whether user-supplied or module-discovered) undergo rigorous syntax validation against expected types (e.g., IPv4, domain) before storage. Data is persisted as strict strings, structurally preventing injection attacks.
* **Component Isolation & Least Privilege:** Internal components interact only through strictly defined boundaries. Modules communicate exclusively with the `Dispatcher` and have zero awareness of the database, other modules, or the user interface.
* **Opaque Project Identifiers:** The `Repository` abstracts physical storage by generating temporary, ephemeral project identifiers during runtime. No core component other than the `Repository` has access to the true project IDs. This indirect referencing prevents data leakage and mitigates IDOR (Insecure Direct Object Reference) vulnerabilities in future multi-user deployments.
## Vision & Scalability
ReconSR is designed as a decoupled framework for Attack Surface Discovery and Mapping. Our long-term goal is to evolve the project from a standalone CLI tool into a comprehensive Attack Surface Management (ASM) intelligence platform. By strictly separating the execution engine, data storage, and external modules, the architecture mitigates technical debt and ensures the system can grow organically to meet enterprise demands.
### Future Goals
While the current alpha release is focused on automating point-in-time investigations, our long-term vision includes expanding the platform's operational capabilities:
* **Collaborative Workspaces:** We aim to implement multi-user environments where distributed security teams can work simultaneously on complex investigations, sharing real-time insights and graph visualizations within a unified project scope.
* **Continuous Monitoring:** We plan to extend ReconSR's capabilities to include continuous infrastructure monitoring, running alongside traditional single-run reconnaissance. Future features will focus on scheduled scanning, state comparisons, and alerting teams to unintended public exposures (e.g., forgotten subdomains, exposed sensitive data) or infrastructure changes. This paves the way for potential on-premise enterprise deployments or managed SaaS offerings.
* **AI-Assisted Analysis:** To enhance the efficiency of investigations, we plan to enable the use of AI for analyzing large intelligence datasets, uncovering hidden threats, mapping non-obvious attack vectors, and interpreting complex infrastructure relationships.
## Project Roadmap
### Completed
### Upcoming
- Additional API-backed passive intelligence modules.
- Active reconnaissance capabilities.
## Authors & License
**License:** ReconSR is distributed under the **PolyForm Noncommercial License 1.0.0**. All intellectual property and core development rights belong strictly to the individual authors: **roolsec** and **underhax**.
As we continue to evolve the framework, we are open to dialogue regarding enterprise integrations, partnerships, and commercial applications. For business inquiries, collaboration, or custom licensing discussions, please reach out to the development team:
* **roolsec:** roolsec [at] cdua [dot] org
* **underhax:** underhax [at] cdua [dot] org
|
|
View detailed architecture
### 1. Reactive Execution Pipeline (`internal/pipeline`) The core of ReconSR is a non-blocking reactive loop. The data flows in a cycle: **Dispatcher → Modules → Processor → Repository → Dispatcher**, continuing until no new entities remain. - **Controller** (`internal/controller`): Serves as the integration boundary (Facade) between external presentation layers (currently the CLI) and the core engine. By strictly isolating user interaction from the core, it enables the future addition of diverse interfaces—such as Web GUIs, REST APIs, or automated bots—without altering the underlying system architecture. Operationally, it orchestrates the initial input flow by delegating target verification to the Validator and Scope Manager before initializing the reconnaissance cycle with validated seed entities. - **Dispatcher** (`internal/dispatcher`): Routes entities to modules based on a type-indexed registry (`domain` → DNS, WHOIS, etc.). Tracks completed functions per entity to prevent redundant execution. Enforces a configurable global timeout per module call. - **Processor** (`internal/processor`): Validates module output against the contract (rejects rogue functions, incomplete data, syntax errors). Normalizes entity types via the Validator and checks scope boundaries via the Scope Manager. - **Repository** (`internal/repository`): A centralized data access layer. All database operations are strictly isolated here (Repository pattern) to ensure the core remains database-agnostic, facilitating seamless future migrations from the current per-project SQLite setup to enterprise RDBMS (e.g., PostgreSQL). Handles persistence, entity deduplication, and dispatch batching. ### 2. Supporting Infrastructure - **Scope Manager** (`internal/scopemanager`): The operational firewall. Applies strict reconnaissance boundaries configured by the user in `configs/scope.txt` via allow/block rules (supporting domain suffix matching, IP CIDR ranges, and exact entity matches). Operating within these technical parameters facilitates adherence to authorized Rules of Engagement (legal compliance) and helps mitigate "scope explosion" (infinite recursive crawling into third-party infrastructure). - **Validator** (`internal/validator`): Centralized entity type normalization and syntax validation. Automatically classifies domains vs. subdomains, IPv4 vs. IPv6, and standard vs. extra emails (those containing non-standard characters like quotes or brackets). - **Report Renderer** (`internal/report`): Recursive ASCII tree visualization of the project relationship graph with scope-awareness (Out-of-Scope markers, cycle detection). - **Interactive Visualizer** (`internal/html`): Generates a dynamic, draggable HTML representation of the entity relationship graph. Features interactive layouts and togglable node labels to facilitate visual analysis of complex attack surfaces. ### 3. External Intelligence & API Strategy ReconSR combines zero-configuration public sources with user-configured API integrations: - **Keyless Integration**: Public-source modules can operate without user accounts or API keys, subject to provider limits and availability. - **User API Keys**: API-backed modules expose their functions only when the corresponding user-provided key is configured locally. Some integrations may also support optional keys while preserving keyless operation. - **Demo Mode**: Supported key-based modules can be explicitly switched to bundled sample data by configuring their service key as `demo-api-key`. This lets users explore module output volume and data structure before deciding whether to obtain real provider credentials, without querying third-party APIs. - **Rate Limiting & ToS Awareness**: Both keyless and authenticated providers enforce their own quotas, rate limits, Terms of Service, and data licensing rules. Users are responsible for obtaining credentials where required and complying with each provider's policies. - **Module Interface**: The system follows a strict **"Black Box" contract**. Developers can extend ReconSR capabilities without needing to understand the internal core logic, routing, or database structures.View details (1 function)
- `decompose`: Hierarchical decomposition of deep subdomains. Extracts the organizational domain (eTLD+1 via the Public Suffix List) and all intermediate parent subdomains, using the `Applied` flag to prevent redundant re-processing.View details (27 functions)
A highly specialized intelligence module for comprehensive DNS reconnaissance. Every record type is treated as a critical intelligence vector (27 functions total): #### **Infrastructure & Continuity** - `preflight_dns`: Lightweight zone health validation that tags resolvable targets with `dns_ok` and flags broken zones before higher-cost enumeration begins. - `get_ip`: IPv4/IPv6 resolution (A/AAAA). - `get_ns`: Identification of authoritative name servers with validation and scope analysis. - `get_mx`: Mail exchange discovery with priority sorting plus extraction of validated `mx_host` infrastructure nodes. - `get_soa`: Extracts the raw SOA record, the Serial value, the validated Primary NS (MNAME), and the validated Responsible Email (RNAME). - `get_cname`: Mapping of canonical aliases for the target and `www.` prefix, differentiating in-scope aliases from external `cname_target` infrastructure. - `check_wildcard`: Proactive detection via random subdomain probing. #### **Identity & Trust Policy** - `get_caa`: Extracts authorized CAs as typed infrastructure nodes and surfaces validated `iodef` violation-reporting mailboxes. - `get_dmarc`: Retrieves the DMARC policy and extracts failure (`ruf`) and aggregate (`rua`) emails; detects external reporting (OOS). - `get_dkim`: Retrieves full DKIM records via brute-force of 33 common and 2 dynamic selectors. - `get_domainkey`: Extraction of legacy cryptographic records. - `get_txt`: Retrieval of full SPF records alongside general TXT data aggregation. #### **Cryptographic Keys & Protocols** - `get_dnskey`: Extraction and categorization of KSK and ZSK signing keys. - `get_ds`: Mapping of Delegation Signer digests (SHA-1/256/384). - `get_cert`: Extraction of raw certificate payloads (PKIX, PGP, SPKI). - `get_sshfp`: Verification of SSH public key fingerprints for diverse algorithms. - `get_hip`: Decodes Host Identity Protocol parameters, including HIT/public keys and validated HIP rendezvous servers. - `get_ipseckey`: Unmasks VPN gateway topology (IPs/domains) and associated public keys with validated gateway classification. #### **Service & Metadata Discovery** - `get_srv`: Brute-forcing of 33 service prefixes (SIP, XMPP, LDAP, Kerberos, CalDAV, Matrix, etc.). - `get_tlsa`: DANE certificate fingerprinting with brute-force of 7 port-protocol prefixes (`_443._tcp`, `_25._tcp`, `_465._tcp`, `_587._tcp`, `_993._tcp`, `_853._tcp`, `_443._udp`). - `get_svcb`: Parallel decoding of both SVCB (type 64) and HTTPS (type 65) parameters including ALPN, ECH, IP hints, and port. - `get_naptr`: Extraction of service identifiers and validated replacement targets, including `_service._proto.domain` delegation patterns. - `get_uri`: Native URI resolution for mapped applications (priority/weight mapping). - `get_loc`: Precise decoding of physical coordinates (Lat/Lon/Alt/Size/Precision). - `get_hinfo`: Disclosure of CPU/OS metadata with automated noise filtering. - `get_rp`: Extraction of the Responsible Person mailbox and TXT reference domains as linked nodes. - `get_nsec`: Proactive zone-walking via NXDOMAIN triggers to uncover hidden subdomains and record coverage hints.View details (3 functions)
Specialized discovery of cryptographic communication keys linked to organizational identities: - **Hashing Architecture**: Implementation of RFC 7929/8162 (SHA256/Base32) for deterministic lookup hashing. - **Dual-Input Logic**: - **Email Address**: Targeted, direct cryptographic key lookup for the specified local part. - **Domain/Subdomain**: Optional brute-force of 15 administrative aliases (`admin`, `support`, `noc`, `security`, `abuse`, etc.); disabled by default via network options and available for explicit opt-in. - `preflight_dns`: Zone health validation for the target email domain before cryptographic lookups are performed. - `get_openpgpkey`: Discovery of PGP public keys via OPENPGPKEY DNS records. - `get_smimea`: Extraction of S/MIME certificate parameters with DANE mapping.View details (1 function)
- `get_whois`: Fallback-oriented architecture using RDAP as primary and TCP 43 as secondary. Features recursive registry discovery starting from `whois.iana.org` and registry-specific query handling (JPRS, Verisign, DENIC, NIC.name), models registrar/registrant hierarchies through anchor nodes, and extracts role-aware contacts, addresses, dates, name servers, domain status, DNSSEC state, and registrar metadata such as registrar URL, WHOIS server, and IANA ID.View details (1 function)
View details (1 function)
View details (1 function)
- `get_domains`: Passive certificate-identity harvesting through configurable Certificate Transparency sources, including `crt.sh`, direct PostgreSQL access to `crt.sh`, and `CertSpotter`. Discovers subdomains, wildcard subdomains, and certificate-bound email identities, attaches expiration metadata to both hostname and email identities, emits explicit `expired` status where applicable, and summarizes subdomains with expired certificates separately for triage.View details (1 function)
- `get_hosts`: Queries the `HackerTarget` passive DNS dataset to identify validated domain and subdomain nodes and their directly linked resolved IP nodes. Supports an optional API key; without one, requests use the public keyless endpoint and remain subject to IP-based service limits. Includes automatic retry logic, API quota detection, and out-of-scope classification.View details (1 function)
- `get_domains`: Passive subdomain enumeration through the `anubisdb.com` Anubis database. Returns validated subdomains and wildcard subdomains, deduplicates results, and filters ARPA/out-of-scope noise before graph insertion.View details (1 function)
- `parse_ambiguous`: Resolution of ambiguous IPv4 addresses containing leading zeros. Decodes input (e.g., `012.012.012.012`) into both strict decimal (`12.12.12.12`) and POSIX-compliant octal (`10.10.10.10`) formats to identify obfuscation and misconfigurations.View details (6 functions)
Passive reconnaissance of IPv4/IPv6 addresses via reverse DNS, public blacklists, and RIPEstat data endpoints to uncover network identity and reputation: - `get_ptr`: Performs reverse DNS lookups to resolve IPs back to their mapped domains. - `get_asn`: Resolves the originating Autonomous System Number (ASN) and BGP prefix via Team Cymru DNS TXT queries. - `get_tor`: Detects if the IP is an active Tor exit node using official DNSBL checks (`dnsel.torproject.org`, `dan.me.uk`). - `get_rbl`: Checks the IP against major Real-time Blackhole Lists (Spamhaus, Barracuda, Spamcop) to identify spam/botnet reputation. - `get_ip_info`: Extracts the network name (`netname`) and description from RIPE WHOIS records. - `get_ip_abuse_contacts`: Retrieves dedicated abuse reporting email addresses registered to the specific IP allocation.View details (1 function)
View details (1 function)
View details (3 functions)
Offline IPv4/IPv6 enrichment backed by locally installed IP2Location/IP2Proxy BIN databases under `data/ip2location`: - `get_geo_ip`: Extracts geolocation, ISP, reverse-IP domain, usage type, mobile network metadata, connection speed, address type, IAB category, etc. from DB11 Geo IP data. - `get_ip_asn`: Resolves ASN, AS owner, linked AS domain, AS usage type, and AS CIDR from IP2Location ASN data. - `get_proxy_check`: Detects proxy/VPN/Tor/datacenter/residential/privacy-network indicators through IP2Proxy data, extracting fraud score, last-seen age, provider, reverse-IP domain, usage type, and threat-derived tags such as scanner, spam, botnet, etc.View details (4 functions)
Offline IPv4/IPv6 enrichment backed by locally installed MaxMind MMDB databases under `data/maxmind`: - `get_geo_ip`: Extracts comprehensive geolocation metadata (city, region, country, coordinates, timezone, etc.) from City databases. - `get_ip_asn`: Resolves Autonomous System Number (ASN), associated organization, ISP, etc. from ASN and ISP databases. - `get_proxy_check`: Identifies anonymous IPs, VPNs, Tor exit nodes, etc. from Anonymous IP databases, emitting standardized threat tags. - `get_mm_enterprise_data`: Provides maximum data density by aggressively parsing Enterprise databases. Combines all available geo, ASN, ISP, connection type, user type, etc. into a single unified output.View details (4 functions)
Deep analysis of Autonomous System Numbers via RIPEstat API to map network hierarchies, ownership, and announced subnets: - `get_asn_peers`: Constructs a strict linear transit chain by identifying the largest upstream provider at each hop, revealing who the ASN buys transit from. - `get_asn_prefixes`: Retrieves all IPv4/IPv6 CIDR blocks (BGP prefixes) currently announced by the ASN. - `get_asn_info`: Resolves the official legal holder (organization name) of the Autonomous System. - `get_asn_abuse_contacts`: Extracts abuse reporting email addresses associated with the ASN infrastructure.View details (3 conditional functions)
- `get_idb_shodan`: Passive enrichment of IPv4/IPv6 targets through the public Shodan InternetDB endpoint. Extracts PTR hostnames, open ports, service tags, known CVEs, and CPE fingerprints for rapid exposure triage. - `get_shodan_api_ip`: Queries the Shodan Host API for IPv4/IPv6 targets. Extracts reverse-IP domains, ASN, organization, ISP, OS, hostnames, tags, last update, service banners, ports, CVEs, CPEs, SSL/TLS metadata, etc. - `get_shodan_api_domain`: Queries the Shodan DNS Domain API for domains, and optionally subdomains. Extracts passive DNS subdomains and a broad set of DNS-derived entities that can overlap with multiple dedicated DNS modules, including record values, last-seen dates, wildcard markers, historical tags, out-of-scope classifications, etc.View details (2 functions)
API-backed enrichment for domains, optionally subdomains, and IPv4/IPv6 targets through VirusTotal API v3. Without a VirusTotal API key, no functions are advertised to the dispatcher; with a configured key, the module exposes both functions and supports explicit demo mode: - `get_vt_api_domain`: Queries VirusTotal domain metadata and, when enabled, related subdomains. Extracts tags, reputation and threat scores, categories, popularity ranks, JARM, crowdsourced context, certificate identities and fingerprints, DNS-derived entities, expired-certificate subdomain summaries, out-of-scope classifications, etc. - `get_vt_api_ip`: Queries VirusTotal IP metadata and passive DNS resolutions. Extracts ASN, network CIDR, AS owner, geo metadata, JARM, tags, threat scores, last update, passive DNS hostnames, etc.View details (1 function)
- `get_circl_vuln`: Queries the CIRCL Vulnerability API for CVE entities. Supports an optional API key; without one, requests use the public keyless endpoint and remain subject to strict rate limits. Extracts vulnerability summaries, CWE classifications with local descriptions, best available CVSS metrics, affected CPE criteria, EPSS probability and percentile, SSVC/KEV indicators, additional metadata included in CIRCL responses, etc.View details (3 functions)
API-backed exposure and data leak intelligence for domains and IPv4/IPv6 targets through the LeakIX API. Without a LeakIX API key, no functions are advertised to the dispatcher; with a configured key, the module exposes all three functions and supports explicit demo mode: - `get_leakix_domain`: Queries LeakIX domain intelligence. Extracts discovered services grouped by IP/port/protocol, open ports, protocols, software versions, web server headers, favicon hashes, SSL/TLS metadata (JARM, certificate fingerprints, SAN domains, issuer, expiration), SSH properties, leaked credentials, leak severity/type/stage, dataset statistics, network context (ASN, organization, CIDR), geolocation, reverse DNS, MAC addresses, tags, event sources, and leak summaries, with retry, rate-limit handling, and blocked-key detection. - `get_leakix_ip`: Queries LeakIX host intelligence for IPv4/IPv6 targets. Extracts the same comprehensive service, leak, credential, network, and SSL/SSH metadata as the domain function, organized around per-host event groups. - `get_leakix_subdomains`: Queries LeakIX passive subdomain enumeration for domains. Extracts validated subdomains with last-seen dates, distinct IP counts, out-of-scope classification, and passive DNS tags.View completed milestones
- ✅ Reactive pipeline architecture (Controller → Dispatcher → Processor → Repository). - ✅ Scope Manager and entity type Validator. - ✅ Subdomain hierarchy decomposition. - ✅ CLI module configuration and ASCII/HTML report renderers. - ✅ DNS reconnaissance: 27 functions covering infrastructure, identity, cryptography, DNSSEC, service discovery, and DNS health preflight checks. - ✅ RFC 3597 wire-format decoder for DoH binary responses. - ✅ WHOIS/RDAP with multi-registry support, structured registrar/registrant graph anchors, and registrar metadata extraction. - ✅ Certificate Transparency harvesting via configurable CT sources, including `crt.sh`, direct PostgreSQL access to `crt.sh`, and `CertSpotter`, with wildcard identities, certificate-bound email identities, expiration metadata, and summaries of subdomains with expired certificates. - ✅ Passive DNS enumeration via HackerTarget with validated domain/subdomain-to-IP relationships and optional API-key support. - ✅ Hunter.io email intelligence with domain/organization search, contact enrichment, source evidence, and explicit demo mode. - ✅ HaveIBeenPwned data breach intelligence for email targets, extracting compromised data classes, threat tags, metadata, and demo mode. - ✅ Mail security: OPENPGPKEY and SMIMEA discovery with optional administrative alias enumeration and DNS preflight health checks. - ✅ IPv4 ambiguity resolution (Decimal vs. POSIX octal decoding). - ✅ Passive exposure enrichment via Shodan InternetDB and API-backed Shodan Host/DNS intelligence with demo mode. - ✅ Passive subdomain discovery via Anubis DB. - ✅ IP intelligence: PTR, DNSBL (Tor/Spam), RIPE WHOIS metadata (netname, description), and abuse contacts. - ✅ IPinfo API enrichment for IPv4/IPv6 targets, extracting Geo, ASN, Privacy, Mobile, Hosting properties, etc., with Lite/Paid endpoint toggle and demo mode. - ✅ AbuseIPDB reputation checks with abuse scores, report summaries, threat tags, reverse-IP context, and demo mode. - ✅ Offline IP2Location/IP2Proxy enrichment for geolocation, ASN, proxy/VPN/Tor indicators, and related IP metadata. - ✅ Offline MaxMind enrichment via locally installed MMDB databases for geolocation, ASN, proxy/VPN indicators, and comprehensive Enterprise data aggregation. - ✅ ASN intelligence: Transit peers hierarchy, BGP prefixes (CIDR), legal holder, and abuse contacts via RIPEstat. - ✅ VirusTotal API enrichment for domain/IP reputation, passive DNS, certificate, DNS-derived, and threat-intelligence findings with demo mode. - ✅ CIRCL vulnerability lookup for CVE enrichment with CVSS, CWE, EPSS, SSVC/KEV, CPE, and related vulnerability metadata. - ✅ LeakIX exposure and data leak intelligence for domains and IPs, including service discovery, leaked credentials, SSL/SSH metadata, subdomain enumeration, and demo mode.标签：EVTX分析
