vgeorgiev90/CallStackSpoof

# Windows x64 Call Stack Spoofing ### Overview This project is a Windows x64 call stack spoofing implementation built using C++ and x64 assembly, with full awareness of PE exception metadata and unwind information. The goal of the project is educational: to deeply understand how Windows constructs, unwinds, and validates call stacks at runtime, and to prepare for advanced Windows internals and exploit development topics. Rather than relying on hardcoded stack layouts or fragile heuristics, this implementation parses real unwind metadata from target modules and constructs synthetic call stacks that are consistent with Windows x64 unwinding rules. ### Key Features - Unwind-aware fake stack construction - Parses the Exception Directory (IMAGE_DIRECTORY_ENTRY_EXCEPTION) - Handles chained unwind info - Computes accurate stack frame sizes - Dynamic spoof frame generation - Builds synthetic frames from real exported functions - Supports offsets into functions (post-prolog spoofing) - Runtime gadget discovery - Filters gadgets using unwind metadata safety checks - Assembly-level stack pivot & restore - Restores original execution flow without crashing - Multi-argument API invocation ### High-Level Architecture CallStackSpoof() ├─ Parsing system DLL to extract all potential jump gadgets ├─ Parse spoof targets function unwind information ├─ Build synthetic frames info array ├─ Select safe jump gadget ├─ Prepare a structure that holds all info about spoof targets and api to be called ├─ Invoke Spoof() (assembly) │ ├─ Save non-volatile registers │ ├─ Construct fake frames on stack │ ├─ Jump to target API │ └─ Restore stack & registers └─ Return to original caller ### Technical Details Windows x64 Unwind Parsing The project manually parses: - RUNTIME_FUNCTION - UNWIND_INFO - UNWIND_CODE Handled unwind operations include: - UWOP_PUSH_NONVOL - UWOP_ALLOC_SMALL - UWOP_ALLOC_LARGE - UWOP_SAVE_NONVOL - UWOP_SAVE_NONVOL_FAR - UWOP_PUSH_MACHFRAME - UWOP_SAVE_XMM128 - UWOP_SAVE_XMM128_far Each unwind sequence is translated into: - Stack frame size - Saved non-volatile register offsets - Frame pointer usage detection At the moment functions using UWOP_SET_FPREG are explicitly detected and excluded to avoid incorrect frame reconstruction. Synthetic Frame Construction Each spoofed frame includes: - Correct return RIP (post-prolog or custom offset) - Accurate stack reservation size A termination frame for safe unwinding Frames are stacked exactly as Windows expects, allowing tools such as stack walkers or debuggers to observe a plausible call stack. Jump Gadget Selection The project dynamically scans executable sections for (with a small change any other non-volatile register can be used): jmp qword ptr [rbx] Each candidate gadget is validated by: - Locating its enclosing function - Parsing its unwind info - Rejecting gadgets with unsafe save-nonvolatile offsets - Rejecting frame-pointer-based functions Only unwind-safe gadgets are used. Assembly Trampoline (Spoof) The assembly routine performs: - Saving all non-volatile registers - Extracting the original return address - Building synthetic frames directly on the stack - Jumping to the target API - Restoring the original stack and registers - Returning execution safely to the original caller This avoids call instructions and preserves full control over stack layout. ### Example Usage A simple proof-of-concept is included to demonstrate how the call stack spoofing mechanism can be used in practice. The PoC performs a standard sequence of actions: 1. Allocate executable memory using `NtAllocateVirtualMemory` 2. Write a payload using `WriteProcessMemory` 3. Execute the payload using `CreateThread` All API calls are executed through the spoofing mechanism, such that the observed call stack appears to originate from legitimate Windows thread initialization routines. For this example, two spoofed frames are used: Additional frames can be added if desired. #### Preparing Spoof Targets Each spoofed frame is described using a `SPOOF_TARGET` structure. This structure defines: - The address of the function to spoof - The module in which the function resides An optional offset from the function start (used to land after the prolog) First, obtain handles to the required modules and resolve the function addresses: // Handles to the modules that are required HMODULE hMod = GetModuleHandleA("ntdll.dll"); HMODULE hMod2 = GetModuleHandleA("kernel32.dll"); // Prepare information about the spoof targets SpoofApi1.funcAddress = (ULONG_PTR)GetProcAddress(hMod, SpoofName1); SpoofApi1.hModule = hMod; SpoofApi1.offsetFromStart = 0x21; SpoofApi2.funcAddress = (ULONG_PTR)GetProcAddress(hMod2, SpoofName2); SpoofApi2.hModule = hMod2; SpoofApi2.offsetFromStart = 0x14; The offsets are chosen to ensure that execution resumes after the function prolog, matching realistic return addresses observed in legitimate call stacks. #### Configuring the Spoofed Call Chain Once the spoof targets are prepared, pointers to them are stored in an array. This array defines the synthetic call stack that will be constructed at runtime. // Store them in an array for syntetic frame preparations spoofArray[0] = &SpoofApi1; spoofArray[1] = &SpoofApi2; apiCallInfo.spoofFramesCount = 2; apiCallInfo.spoofFramesTargetsArray = spoofArray; The order of the array corresponds to the order of frames as they will appear on the stack. #### Specifying the Target API Before invoking the spoofed call, the target API information must be populated in the `API_CALL_INFO` structure. This includes: - The address of the function to be executed - The number of arguments it expects apiCallInfo.pFuncAddr = pNtAllocateVirtualMemory; apiCallInfo.apiFuncArgsCount = 6; The `retVal` member of the structure is intentionally left uninitialized, as it is populated internally with the return value of the spoofed call. #### Executing the Spoofed Call With all required information prepared, the spoofed API call can be executed using `CallStackSpoof`. Arguments are passed as variadic parameters and are automatically placed into the correct registers and stack locations. PVOID addr = NULL; SIZE_T size = sizeof(shellcode); CallStackSpoof( &apiCallInfo, // NtAllocateVirtualMemory (uint64_t)(HANDLE)-1, // ProcessHandle (uint64_t)&addr, // *BaseAddress (uint64_t)0, // ZeroBits (uint64_t)&size, // RegionSize (uint64_t)(MEM_COMMIT | MEM_RESERVE), // AllocationType (uint64_t)PAGE_EXECUTE_READWRITE // Protect ); After the call completes, the return value can be accessed via the `retVal` field: status = (NTSTATUS)(ULONG_PTR)apiCallInfo.retVal; printf("[+] Allocation: %p, status: 0x%08X\n", addr, status); Subsequent API calls (such as `WriteProcessMemory` and `CreateThread`) reuse the same spoofed call chain by updating only the target function address and argument count. #### Resulting Call Stack (Simplified) When observed under a debugger or stack-walking tool, the resulting call stack resembles the following: 0:000> ~0 k Call Site ntdll!NtAllocateVirtualMemory+0x3 ntdll!RtlQueryCriticalSectionOwner+0xd2 <-- jump gadget KERNEL32!BaseThreadInitThunk+0x14 ntdll!RtlUserThreadStart+0x21 This demonstrates how the project constructs a plausible and unwind-consistent call stack while executing arbitrary APIs. Allocating memory  Writing the shellcode  Creating an execution thread  ### Limitations & Known Constraints This project was mainly done for learning, so i guess that most likely some things can be done better :) ### TODO / Future Work #### Security & Ethics Notice This project is provided for educational and research purposes only. It is intended to: - Understand Windows x64 internals - Learn unwind metadata and call stack mechanics - Prepare for advanced defensive and offensive security research Do not use this code in unauthorized environments.
