greenpdx/crmonban

# CR Monban  基于 nftables 的入侵防御系统，具备攻击者情报收集功能。 这是 fail2ban/crowdsec 的现代替代方案，直接使用 nftables 并收集有关攻击者的综合信息。 ## 功能 - **nftables 集成** - 使用 nftables 集合实现 O(1) 的 IP 封禁（无需 iptables） - **日志监控** - 实时监控 auth.log、nginx、apache、postfix、dovecot - **攻击者情报** - 自动收集： - GeoIP 位置（国家、城市、坐标） - WHOIS 数据（组织、注册商、滥用联系人） - 反向 DNS - ASN 和 ISP 信息 - Shodan 数据（可选，需要 API key） - AbuseIPDB 威胁评分（可选，需要 API key） - **SQLite 数据库** - 用于封禁、事件、情报和白名单的持久化存储 - **CLI 界面** - 完整的命令行管理 - **Daemon 模式** - 具有自动封禁功能的 后台监控 - **白名单支持** - 保护受信任的 IP 免于被封禁 - **D-Bus 界面** - 提供外部控制和事件通知，便于与其他应用程序集成 - **Zone 支持** - 支持基于 Zone 的感知封禁，具备信任级别和隐式白名单 - **eBPF 快速路径** - 可选的 eBPF 集成，实现亚微秒级的 IP 封禁 - **共享白名单** - 多种白名单来源（数据库、Zone、文件、网络） - **SIEM 导出** - 支持 CEF、LEEF、Syslog (RFC 5424) 和 JSON 格式 ## 安装说明 ### 从源码构建 ``` # Clone the repository git clone https://github.com/greenpdx/crmonban.git cd crmonban # Build cargo build --release # Install (optional) sudo cp target/release/crmonban /usr/local/bin/ # Install D-Bus policy file sudo cp dbus/org.crmonban.Daemon.conf /usr/share/dbus-1/system.d/ sudo systemctl reload dbus ``` ### 依赖项 - Rust 2024 edition - nftables（必须可用 nft 命令） - 支持 nftables 的 Linux 内核 - D-Bus（用于支持 D-Bus 界面） ## 快速入门 ``` # Generate default configuration sudo mkdir -p /etc/crmonban crmonban gen-config -o /etc/crmonban/config.toml # Create database directory sudo mkdir -p /var/lib/crmonban # Initialize nftables table and sets sudo crmonban init # Start the daemon in foreground (for testing) sudo crmonban start -f # Or start as background daemon sudo crmonban start ``` ## CLI 命令 ``` crmonban start [-f] Start monitoring daemon (-f for foreground) crmonban stop Stop the daemon crmonban status Show daemon status crmonban ban [-d secs] Ban an IP address (-d duration, 0=permanent) crmonban unban Unban an IP address crmonban list [-f format] List active bans (table/json/simple) crmonban intel [-r] [-j] Gather intel on IP (-r refresh, -j json) crmonban whitelist add Add IP to whitelist crmonban whitelist rm Remove IP from whitelist crmonban whitelist list List whitelisted IPs crmonban logs [-l limit] Show recent activity logs crmonban stats Show attack statistics crmonban init Initialize nftables configuration crmonban flush --yes Flush all bans (dangerous!) crmonban gen-config [-o path] Generate default configuration ``` ## 配置 配置文件：`/etc/crmonban/config.toml` ### 常规设置 ``` [general] db_path = "/var/lib/crmonban/crmonban.db" pid_file = "/var/run/crmonban.pid" log_level = "info" # trace, debug, info, warn, error auto_intel = true # Gather intel automatically on ban default_ban_duration = 3600 # Default ban duration in seconds ``` ### nftables 设置 ``` [nftables] table_name = "crmonban" chain_name = "input" set_v4 = "blocked_v4" set_v6 = "blocked_v6" priority = -100 # Chain priority (lower = earlier) ``` ### 情报设置 ``` [intel] geoip_enabled = true rdns_enabled = true whois_enabled = true timeout_secs = 10 # Optional API keys for enhanced intelligence # shodan_api_key = "your-key" # abuseipdb_api_key = "your-key" ``` ### 服务监控 ``` [services.ssh] enabled = true log_path = "/var/log/auth.log" max_failures = 5 # Failures before ban find_time = 600 # Time window (seconds) ban_time = 3600 # Ban duration (seconds) [[services.ssh.patterns]] name = "failed_password" regex = 'Failed password for .* from (?P\d+\.\d+\.\d+\.\d+)' event_type = "failed_auth" [[services.ssh.patterns]] name = "invalid_user" regex = 'Invalid user .* from (?P\d+\.\d+\.\d+\.\d+)' event_type = "invalid_user" ``` ### 可用服务 - **ssh** - SSH 身份验证失败（默认启用） - **nginx** - 速率限制违规 - **apache** - 身份验证失败 - **postfix** - SMTP 身份验证失败 - **dovecot** - IMAP/POP3 身份验证失败 ### D-Bus 设置 ``` [dbus] enabled = true # Enable D-Bus interface system_bus = true # Use system bus (recommended for daemon) ``` ## D-Bus 界面 crmonban 暴露了 D-Bus 接口，供外部应用程序控制 daemon 并接收事件。 **服务**：`org.crmonban.Daemon` **对象路径**：`/org/crmonban/Daemon` ### 方法 | 方法 | 参数 | 返回值 | 描述 | |--------|------------|---------|-------------| | `Status` | - | `StatusInfo` | 获取 daemon 状态 | | `Ban` | `ip: String, duration_secs: u32, reason: String` | `bool` | 封禁 IP 地址 | | `Unban` | `ip: String` | `bool` | 解封 IP 地址 | | `GetBans` | - | `Array` | 列出活跃的封禁 | | `IsBanned` | `ip: String` | `bool` | 检查 IP 是否被封禁 | ### 属性 | 属性 | 类型 | 描述 | |----------|------|-------------| | `Running` | `bool` | 如果可达则始终为 true | | `ActiveBanCount` | `u64` | 活跃封禁的数量 | | `UptimeSeconds` | `u64` | daemon 运行时间（秒） | | `EventsProcessed` | `u64` | 已处理的事件总数 | ### 信号 | 信号 | 参数 | 描述 | |--------|------------|-------------| | `BanAdded` | `ip, reason, source, duration_secs` | 当 IP 被封禁时触发 | | `BanRemoved` | `ip, reason` | 当 IP 被解封时触发 | | `AttackDetected` | `ip, service, event_type` | 每次检测到攻击时触发 | | `DaemonStarted` | - | 当 daemon 启动时触发 | | `DaemonStopping` | - | 当 daemon 停止时触发 | ### 示例：使用 dbus-monitor 监控事件 ``` dbus-monitor --system "interface='org.crmonban.Daemon'" ``` ### 示例：使用 busctl 查询状态 ``` busctl call org.crmonban.Daemon /org/crmonban/Daemon org.crmonban.Daemon Status ``` ## 高级配置 ### Zone 配置 ``` [zones] enabled = true config_file = "/etc/crmonban/zones.yaml" whitelist_threshold = 80 # Trust level for implicit whitelist [[zones.zones]] name = "internal" trust_level = 80 networks = ["10.0.0.0/8", "192.168.0.0/16"] implicit_whitelist = true [[zones.zones]] name = "external" trust_level = 0 networks = ["0.0.0.0/0"] ``` ### SIEM 导出 ``` [siem] enabled = true format = "cef" # cef, leef, syslog, json [[siem.targets]] type = "file" path = "/var/log/crmonban/siem.log" [[siem.targets]] type = "syslog" socket = "/dev/log" [[siem.targets]] type = "webhook" url = "https://siem.example.com/api/events" headers = [["Authorization", "Bearer token"]] ``` ### eBPF 快速路径封禁 ``` [ebpf] enabled = true method = "mapfile" # mapfile, disabled (dbus requires crrouter feature) sync_interval_secs = 60 # Sync with nftables max_entries = 10000 # For mapfile method: [ebpf.method] path = "/sys/fs/bpf/crmonban_blacklist" ``` ### 共享白名单 ``` [whitelist] enabled = true cache_ttl_secs = 300 [[whitelist.sources]] type = "database" # Local crmonban whitelist [[whitelist.sources]] type = "zones" # Zone-based implicit whitelist [[whitelist.sources]] type = "networks" networks = ["10.0.0.0/8", "172.16.0.0/12"] [[whitelist.sources]] type = "file" path = "/etc/crmonban/whitelist.txt" watch = true [[whitelist.sources]] type = "daemon" # Query external daemon via D-Bus (requires crrouter feature) ``` ### 外部 Daemon 集成 在外部防火墙 daemon 中启用 crmonban 插件： ``` # Build with crmonban support cargo build --features crmonban # The plugin provides these JSON-RPC methods: # crmonban.status - Get crmonban daemon status # crmonban.bans - List active bans # crmonban.ban - Ban an IP # crmonban.unban - Unban an IP # crmonban.sync - Sync bans to eBPF ``` ## nftables 结构 crmonban 创建以下 nftables 结构： ``` table inet crmonban { set blocked_v4 { type ipv4_addr flags timeout } set blocked_v6 { type ipv6_addr flags timeout } chain input { type filter hook input priority -100; policy accept; ip saddr @blocked_v4 drop ip6 saddr @blocked_v6 drop } } ``` ## Systemd 服务 创建 `/etc/systemd/system/crmonban.service`： ``` [Unit] Description=crmonban intrusion prevention system After=network.target [Service] Type=forking PIDFile=/var/run/crmonban.pid ExecStart=/usr/local/bin/crmonban start ExecStop=/usr/local/bin/crmonban stop ExecReload=/bin/kill -HUP $MAINPID Restart=on-failure [Install] WantedBy=multi-user.target ``` 启用并启动： ``` sudo systemctl enable crmonban sudo systemctl start crmonban ``` ## 示例 ### 手动封禁 24 小时 ``` sudo crmonban ban 192.168.1.100 -d 86400 -r "Port scanning" ``` ### 收集某个 IP 的情报 ``` crmonban intel 8.8.8.8 ``` 输出： ``` IP: 8.8.8.8 Gathered: 2024-01-15 10:30:00 UTC --- Location --- Country: United States (US) City: Mountain View, California Coordinates: 37.4056, -122.0775 Timezone: America/Los_Angeles --- Network --- ASN: AS15169 (Google LLC) ISP: Google LLC Reverse DNS: dns.google --- Flags --- ⚠ Hosting/Datacenter ``` ### 查看攻击统计 ``` crmonban stats ``` ### 将受信任的服务器加入白名单 ``` sudo crmonban whitelist add 10.0.0.1 -c "Internal monitoring server" ``` ## 架构 ``` ┌─────────────────────────────────────────────────────────────┐ │ crmonban │ ├─────────────────────────────────────────────────────────────┤ │ CLI Interface │ │ ├── ban/unban/list │ │ ├── whitelist management │ │ ├── intel gathering │ │ └── statistics │ ├─────────────────────────────────────────────────────────────┤ │ Daemon │ │ ├── Log Monitor (watches files, matches patterns) │ │ ├── Event Processor (counts failures, triggers bans) │ │ ├── Intel Gatherer (GeoIP, WHOIS, rDNS) │ │ └── Cleanup Task (removes expired bans) │ ├─────────────────────────────────────────────────────────────┤ │ Firewall (nftables) │ Database (SQLite) │ │ ├── Table: crmonban │ ├── bans │ │ ├── Sets: blocked_v4/v6 │ ├── events │ │ └── Chain: input │ ├── intel │ │ │ ├── whitelist │ │ │ └── activity_log │ └─────────────────────────────────────────────────────────────┘ ``` ## 许可证 LGPL 2 ## 贡献 欢迎贡献！请在 GitHub 上提交 issue 或 pull request。

标签：CISA项目, Docker镜像, nftables, Rust, 入侵防御系统, 可视化界面, 威胁情报, 威胁猎捕, 开发者工具, 网络流量审计, 通知系统
