ConnorHowell/medc17-checksum-tool

# MEDC17 Checksum Tool Checksum analyzer and corrector for Bosch MED17/EDC17 ECU firmware binaries. ## Overview Analyzes and corrects checksums in Bosch MED17 and EDC17 ECU firmware files. Supports CRC32, ADD32, and ADD16 algorithms. ## Features - ✅ **Automatic block detection** - Identifies all checksum blocks in the binary - ✅ **Three algorithms** - CRC32, ADD32, and ADD16 support - ✅ **Instant CRC32 solving** - GF(2) matrix algebra - ✅ **RSA signature forging** - Generates valid Bleichenbacher signatures - ✅ **CVN correction** - Fix Calibration Verification Number to match original - ✅ **Safe operation** - Never overwrites original files ### Need Help with Your VW Group ECU Project? Got a custom ECU tool you want built? Need reverse engineering work done? Working on something ambitious for VW Group control units? **[Howell Systems Ltd](https://howellsystems.co.uk)** provides professional reverse engineering and custom embedded software development for the automotive aftermarket. **[Get in touch →](https://howellsystems.co.uk)** ## Requirements Python 3.7+ with `rich` package: pip install rich ## Usage ### Analyze checksums (read-only) python main.py firmware.bin ### Correct checksums python main.py firmware.bin --correct --output firmware_corrected.bin ### Correct checksums and CVN python main.py modified.bin --correct --fix-cvn original.bin --output fixed.bin ### Options -h, --help Show help -c, --correct Correct invalid checksums -o OUTPUT, --output Output file path for corrected binary --fix-cvn ORIGINAL Fix CVN to match the CVN from ORIGINAL file ## How It Works ### Checksum Block Structure ECU firmware contains multiple Bosch blocks with checksums protecting different regions: - **Absolute constants** (0xC0) - **Customer Block** (0x30) - **Application software** (0x40) - **Dataset** (0x60) - **Startup Block** (0x10) ### Two-Pass Correction 1. **Pass 1 (ADD32/ADD16)**: Modifies last 4 bytes of checksummed regions using simple arithmetic 2. **Pass 2 (CRC32)**: Uses GF(2) matrix algebra to solve for exact dCSAdjust value instantly ### CRC32 Mathematical Solving Traditional methods brute-force billions of values. This tool models CRC32 as 32 linear equations over GF(2), constructs a 32×32 matrix, and solves using Gaussian elimination. ### CVN (Calibration Verification Number) The CVN is a CRC32 checksum over specific memory regions that OBD-II diagnostics report to verify calibration integrity. When modifying calibration data, the CVN changes and will no longer match dealer records. **How CVN correction works:** Instead of hardcoding regions per ECU variant, this tool dynamically discovers the CVN configuration structure directly from the binary: 1. **Structure Discovery** - Locates the CVN config by scanning for patterns (we always know that DS0 will appear in the main struct) 2. **Region Extraction** - Reads the actual memory regions from the structure (typically ASW + Dataset areas, but this can vary by ECU) 3. **Patch Location** - Calculates an optimal patch point within the CVN range but outside checksum-critical areas 4. **GF(2) Solving** - Uses matrix algebra to find a 4-byte patch value that produces the target CVN This approach works across different MED17/EDC17 variants without requiring variant-specific configuration. **Future enhancement:** A CSV database of software version numbers and their corresponding CVN values could eliminate the need for the original binary file entirely. ## Technical Details | Algorithm | Initial Value | Expected Result | Method | |-----------|---------------|-----------------|---------| | **CRC32** | 0xFADECAFE | 0x35015001 | IEEE 802.3 (0xEDB88320) bit-reversed polynomial | | **ADD32** | 0xFADECAFE | 0xCAFEAFFE | 32-bit dword sum (overflow ignored) | | **ADD16** | 0xFADECAFE | 0xCAFEAFFE | Sum of 16-bit words from 32-bit dwords | ## TODO Future enhancements planned: - [ ] **Sync blocks** - WinOLS references these, what are they?? - [ ] **ECM/Code monitoring checksums** - Make sure all monitoring checksums are corrected - [ ] **Variant Dataset Correction** - Even with just calibration changes WinOLS will make changes to the VDS block epilog if it exists, needs investigation - [ ] **Extended testing** - Validation with code section modifications beyond calibration changes Contributions welcome! ## License MIT License - see [LICENSE](LICENSE) ## Disclaimer
