khuynh22/mcp-wireshark

# mcp-wireshark  [](https://badge.fury.io/py/mcp-wireshark) [](https://github.com/khuynh22/mcp-wireshark/actions/workflows/ci.yml) [](https://opensource.org/licenses/MIT) [](https://www.python.org/downloads/) ## Quick start with Claude Code pip install mcp-wireshark claude mcp add --transport stdio --scope user mcp-wireshark -- mcp-wireshark That's it. Open Claude Code and try: `--scope user` makes the server available across every Claude Code project. Drop the flag to install it for the current project only. See [`claude mcp` docs](https://code.claude.com/docs/en/mcp) for more. ### Verify the install claude mcp list You should see `mcp-wireshark` listed. Inside Claude Code, ask: If `tshark` is on your `PATH`, it returns the version. If not, see [troubleshooting](#troubleshooting). ## Tools The server exposes 13 tools, split cleanly between **read tools** (safe, no side effects) and **write tools** (capture traffic or write files). Both groups are annotated with the standard MCP `readOnlyHint` so any compliant client can surface the distinction. ### Read tools Safe to call freely — they only inspect state. | Tool | What it does | | -------------------- | --------------------------------------------------------------------------------------------- | | `check_installation` | Verify tshark is installed and show version | | `list_interfaces` | List network interfaces available to capture from | | `read_pcap` | Read packets from a `.pcap` / `.pcapng` file (preview + total count) | | `display_filter` | Apply a Wireshark display filter to a pcap | | `summarize_pcap` | High-level summary: I/O stats, protocol hierarchy, top talkers | | `stats_by_proto` | Protocol hierarchy statistics | | `follow_tcp` | Reassemble a TCP stream and return its payload | | `follow_udp` | Reassemble a UDP stream and return its payload | | `expert_info` | tshark expert analysis: warnings, errors, and notes grouped by severity | | `decode_protocol` | Extract protocol fields as a TSV table. Curated defaults for HTTP, DNS, TLS, GOOSE, MMS, SV, SIP, ICMP; arbitrary fields for any other protocol | | `protocol_stats` | Aggregate `-z` reports (protocol hierarchy, conversations, endpoints, HTTP/DNS/SMB stats) | ### Write tools These create files or capture live traffic. Compliant clients may prompt before invoking. | Tool | What it does | | -------------- | -------------------------------------------------------------------------- | | `live_capture` | Capture live traffic from an interface (capped at 5 minutes / 10k packets) | | `export_json` | Export packets from a pcap to a JSON file at a path you choose | ## See it in action These clips run the real tools against [`demo/demo.pcapng`](demo/demo.pcapng) — a short home-network capture. Regenerate them with `python demo/render_gif.py `. **`summarize_pcap` — characterize an unknown capture at a glance**  **`decode_protocol` — filter to a protocol and get a compact table (here: TLS SNI and DNS-over-HTTPS lookups)**  **`expert_info` — let tshark surface the warnings and anomalies for you**  ## Example prompts Drop these into Claude Code as-is: List my network interfaces. Summarize ./traffic.pcap. From ./traffic.pcap, show me only HTTP requests. Follow TCP stream 0 in ./traffic.pcap and tell me what protocol is in it. Capture 30 seconds of traffic on Wi-Fi filtered to tcp.port == 443. Export every DNS packet from ./traffic.pcap to ./dns.json. Decode the GOOSE messages in ./substation.pcapng — only stNum >= 1. Run expert analysis on ./traffic.pcap and group findings by severity. Show me the IP conversations in ./traffic.pcap. ### Useful display filters | Filter | Matches | | ------------------------------------------ | ------------------------------- | | `tcp.port == 80` | HTTP | | `tcp.port == 443` | HTTPS | | `dns` | All DNS | | `http.request` | HTTP requests only | | `ip.addr == 10.0.0.1` | Traffic to/from a specific host | | `tcp.flags.syn == 1 && tcp.flags.ack == 0` | TCP SYN packets only | For substation engineers analyzing IEC 61850 traffic: | Filter | Matches | | ----------------- | --------------------------------- | | `goose` | All GOOSE messages | | `goose.stNum > 0` | GOOSE messages with state changes | | `mms` | All MMS traffic | | `sv` | Sampled Values | ## Other clients Anything that speaks MCP works. The package installs an `mcp-wireshark` binary on `PATH`.

Claude Desktop

{ "mcpServers": { "wireshark": { "command": "mcp-wireshark" } } }

VS Code (Copilot / GitHub Copilot Chat)

Create `.vscode/mcp.json` in your workspace: { "servers": { "wireshark": { "command": "mcp-wireshark" } } }

Cursor / Windsurf / others

Use the same stdio invocation: `command: mcp-wireshark`. No transport flags.

## Prerequisites - Python **3.10+** - [Wireshark](https://www.wireshark.org/download.html) installed; `tshark` reachable on `PATH` Install with `pip` or `uv`: pip install mcp-wireshark # or uvx mcp-wireshark ## Troubleshooting

tshark not found on Windows

Add Wireshark to your **system** `PATH`: 1. Press `Win+R` → run `sysdm.cpl` → **Advanced** → **Environment Variables** 2. Edit `Path` → add `C:\Program Files\Wireshark` 3. Restart your terminal and Claude Code, then re-run `check_installation` (Avoid passing `PATH` through `claude mcp add --env` — values are taken literally, no `%PATH%` expansion.)

Permission denied capturing on Linux

Add yourself to the `wireshark` group, then log out and back in: sudo usermod -aG wireshark $USER

"No packets captured" from live_capture

- Confirm the interface name from `list_interfaces` (Wireshark uses different names than `ifconfig`/`ip`) - On macOS, you may need to install ChmodBPF (ships with the Wireshark `.dmg`) - Check that no display filter is excluding everything

## Development git clone https://github.com/khuynh22/mcp-wireshark.git cd mcp-wireshark python -m venv venv && source venv/bin/activate # Windows: venv\Scripts\activate pip install -e ".[dev]" pytest # tests black src tests # format ruff check src tests # lint mypy src # type check The codebase is organized so new tools land in one of two clearly-scoped files: - **`src/mcp_wireshark/read_tools.py`** — anything that just inspects state - **`src/mcp_wireshark/write_tools.py`** — anything that captures traffic or writes files ## Security Every file path is validated (`..` rejected, extension allow-listed). Every display filter is checked for shell metacharacters. tshark is always invoked via `asyncio.create_subprocess_exec`, never `shell=True`. Hard caps: 10k packets per call, 5 min per live capture. See [SECURITY.md](SECURITY.md). ## License MIT — see [LICENSE](LICENSE).
